Molex Milli-Grid Series Straight Surface PCB Header 8 Contacts 2 mm Pitch 2 Row Shrouded 87832-0820

Name: Molex Milli-Grid Series Straight Surface PCB Header 8 Contacts 2 mm Pitch 2 Row Shrouded 87832-0820
Brand: Molex
SKU: 206299
Price: 1.97 USD
Availability: InStock



Category PCB Headers Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	125V
Brand	Molex
Orientation	Straight
Current	2A
Mount Type	Surface
Housing Material	Nylon
Contact Material	Phosphor Bronze
Series	Milli-Grid
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2mm
Contact Plating	Gold
Number of Contacts	8
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	2.5mm
Mating Pin Length	2mm

Key Features

The connector system uses a 2 x 2 mm grid pattern to optimize high-density PCB interconnections.
Contacts are phosphor bronze with gold plating for excellent conductivity and corrosion resistance.
Designed for 125 V voltage rating and 2 A current carrying capacity suitable for low-power electronics.
Housing is made from durable nylon material, providing insulation and mechanical strength.
Operating temperature range from -55°C to 105°C supports harsh industrial environments.
2.5 mm tail pin length and 2 mm mating pin length ensure secure solder termination and mating reliability.
Surface mount type simplifies PCB assembly and manufacturing processes.

Product Description

Molex 87832-0820 Milli-Grid Series Straight Surface PCB Header is a robust connector designed for high-density wire-to-board applications. Featuring 8 male contacts arranged in 2 rows with a 2 mm pitch, this shrouded header ensures secure and reliable connectivity on printed circuit boards.

The connector employs phosphor bronze contact material with 0.38 μm gold plating for optimum electrical performance and resistance to corrosion. Its nylon housing provides mechanical durability and electrical insulation suitable for industrial and commercial electronics.

Rated for 125 volts and a current capacity of 2 amps, this PCB header performs well under moderate electrical loads. It operates reliably over an extended temperature range from -55°C to 105°C, making it suitable for various environmental conditions.

The surface mount termination type facilitates automated PCB assembly, reducing production times and enhancing manufacturing efficiency. Tail pin and mating pin lengths of 2.5 mm and 2 mm respectively guarantee secure soldering and mating connections.

The connector system is based on a 2 x 2 mm grid pattern for design flexibility in board-to-board and cable-to-board applications. Phosphor bronze contacts plated with gold provide excellent conductivity and mechanical reliability.

Durable nylon housing ensures stable insulation and resistance to mechanical stress. Shrouded design offers contact protection and prevents misalignment during mating. Suitable for industrial, electronics manufacturing, and assembly environments.

This Molex PCB header is ideal for use in electronics components, communication devices, instrumentation, and other applications requiring compact, reliable PCB interconnections. Explore a wide range of PCB connectors and headers on EnvMart for your electronics and industrial needs.
