Artesyn / Advanced Energy High Performance 75W Isolated DC/DC Converter 12V DC Output, 6.25A, 66-160V DC Input ERM75

Free Delivery in India | Lowest Global Shipping Charges

Artesyn / Advanced Energy High Performance 75W Isolated DC/DC Converter 12V DC Output, 6.25A, 66-160V DC Input ERM75

Name: Artesyn / Advanced Energy High Performance 75W Isolated DC/DC Converter 12V DC Output, 6.25A, 66-160V DC Input ERM75
Brand: Artesyn / Advanced Energy
SKU: 150993
Price: 1034.85 USD
Availability: InStock



Category DC/DC Converter Brand Artesyn / Advanced Energy Condition New

Specifications

Country of Origin	Taiwan
Brand	Artesyn / Advanced Energy
Efficiency	91%
Length	57.9mm
Model	ERM75
Depth	12.7mm
Width	36.8mm
Mount Type	Through Hole
Series	ERM75
Maximum Operating Temperature	70°C
Package Type	DIP
Minimum Operating Temperature	-40°C
MTBF	209000h
Number of outputs	1
Maximum Output Power	75W
Maximum Input Voltage	160V dc
Minimum Input Voltage	66V
Output Voltage 1	12V dc
Output Current 1	6.25A
Isolation Voltage	1.5kV dc

Key Features

Operates with an input voltage range of 66 to 160 V DC.
Delivers up to 75 watts of output power efficiently.
Features a compact through hole DIP package measuring 57.9 x 36.8 x 12.7 mm.
Offers excellent reliability with 209000 hours MTBF.
Supports operating temperatures from -40°C to 70°C for rugged use.
Includes 1.5 kV DC isolation voltage for electrical safety.
High efficiency approaching 91% ensures low power loss.
Metal casing with isolated baseplate for heat dissipation and protection.

Product Description

Artesyn / Advanced Energy ERM75 DC/DC Converter is a high-performance 75 watt isolated converter module engineered for demanding railway and industrial applications. The device operates at an output voltage of 12V DC with a maximum output current of 6.25A, providing stable power for sensitive electronics.

This converter supports a wide input voltage range of 66 to 160 V DC, suitable for equipment deployed on railway rolling stock and other rugged environments. It features a compact DIP package with dimensions of 57.9 mm length, 36.8 mm width, and 12.7 mm depth, allowing efficient space utilization.

The ERM75 series ensures durable performance with a mean time between failures (MTBF) of 209000 hours and operates reliably in temperatures ranging from -40°C up to a maximum of 70°C. With a reinforced insulation rating of 3000 VAC rms and an isolation voltage of 1.5 kV DC, these converters provide robust electrical isolation and safety.

The unit achieves high efficiency of 91%, reducing energy dissipation and improving overall system reliability. Its metal case with isolated baseplate design aids thermal management and protects internal components. The standard quarter-brick footprint and through hole mounting facilitate easy integration into printed circuit boards.

This DC/DC converter series is fully encapsulated and designed to meet the rigorous requirements of railway power electronics, industrial control systems, and similar applications demanding stable, isolated DC power conversion.

Operates across a broad input voltage range of 66 to 160 V DC. Offers a steady 12V DC output at 6.25A current. Compact through hole DIP package with a quarter-brick form factor. High MTBF of 209000 hours ensures reliable long-term use.

Wide operating temperature range from -40°C to 70°C. Isolation voltage of 1.5 kV DC for electrical safety and noise immunity. Metal casing with isolated baseplate promotes thermal efficiency. Efficiency up to 91% minimizes heat and energy waste.

Designed for railway and industrial power supply applications.
