Artesyn / Advanced Energy 15W Regulated Isolated DC/DC Converter, 15V DC Output, 1A, 9-36V DC Input, Through AEE01C18-LS

Artesyn / Advanced Energy AEE01C18-LS is a 15W regulated and isolated DC/DC converter engineered for electronic components and power supply applications. Delivering a stable 15V DC output with 1 Ampere current, this converter operates with a wide input voltage range from 9 to 36V DC, ensuring flexibility across various industrial and commercial devices.

The device is mounted via through hole technology, allowing robust mechanical connection and ease of PCB assembly. Featuring an input/output isolation voltage of 1.5kV DC, it provides reliable electrical isolation to protect sensitive electronic circuits.

The compact 1 x 2 inch package measures 50.8 mm in length and 11.3 mm in depth, suitable for space-conscious designs. Its efficiency at 84% ensures minimal energy loss, while a ripple and noise level of 100mV guarantees clean output voltage essential for precision electronics.

Certified to UL and CE standards, this converter complies with industrial safety requirements, suitable for use in manufacturing equipment, instrumentation, and power management applications. The unit also includes protections such as under-voltage lockout, over-current, and short circuit auto-restart, enhancing operational reliability.

Operating temperature ranges up to 71°C without derating, the converter is built to endure typical industrial conditions. The astec ASA-15W series design encapsulates high MTBF values exceeding one million hours, demonstrating robust performance and longevity.

This DC/DC Converter features a regulated output power of 15W suitable for precision applications. It supports maximum input voltage of 36V DC and minimum input voltage of 9V DC. The package type is compact at 1 x 2 inches with length 50.8mm and depth 11.3mm.

Includes 1.5kV DC isolation voltage and operates up to 71°C maximum temperature. The unit maintains an efficiency of 84% and has ripple and noise rating of 100mV for stable output. It utilizes through hole mounting for secure PCB installation.

Designed to meet UL and CE standards for safety and compliance.

Ideal for industrial, laboratory, and manufacturing power systems, this converter supports stable and isolated DC power supply needs. For more advanced power conversion solutions, explore the Artesyn / Advanced Energy product range on EnvMart.
