ABB Variable Speed Drive, 4 kW, 3 Phase, Altivar Series 400V AC 9.5 A ATV320U40N4C

Schneider Electric ATV320U40N4C is a variable speed drive from the Altivar 320 series designed for industrial automation and control applications involving 3-phase asynchronous and synchronous motors. Delivering a power rating of 4 kW with a maximum output current of 9.5 amperes at 400 V AC, this drive provides precise torque and speed control, particularly at low speeds, through advanced flux vector control without the need for sensors.

The compact design enables vertical stacking within machine frames, optimizing panel space. Its robust build, featuring IEC 60721-3-3 class 3C3 coated printed circuit boards, ensures reliable operation in harsh environments and ambient temperatures up to 60°C without additional cooling.

This variable frequency drive supports extended frequency ranges suitable for high-speed motors and incorporates five built-in safety functions configurable through SoMove software, facilitating compliance with relevant machine safety standards. Certifications include CE, UL, CSA, NOM, EAC, and RCM, reflecting its worldwide compliance credentials.

Mounting is designed for vertical panel installation within a ±10-degree deviation, secured via four fixing holes. The drive is ideally suited for Original Equipment Manufacturers (OEMs) servicing sectors such as packaging, material handling, textiles, mechanical actuators, and hoisting applications.

Energy-saving features are integrated, including support for energy-efficient operation of synchronous motors in open-loop configurations. Operational temperature range spans from -10°C to 50°C, accommodating diverse industrial environments.

Compact Altivar 320 series for versatile industrial automation applications. Advanced vector control without sensors for accurate torque and speed. Robust coated circuit boards for harsh environmental resilience. Safety functions integrated to meet machine safety requirements.

Certified CE, UL, CSA, NOM, EAC, and RCM for global compliance. Vertical DIN rail mounting with four fixing points. Compatible with asynchronous and synchronous motors. Wide operating temperature range from -10°C to 50°C.

Supports parallel motor connections and static speed accuracy.

This Schneider Electric Altivar 320 variable speed drive is a high-performance solution for industrial and manufacturing automation, providing reliable speed and torque control in demanding environments. For more options in inverter drives and automation controls, explore EnvMart’s comprehensive catalog.
