Artesyn / Advanced Energy ATA DC/DC Converter, 12V, -12 V, 335 mA Output, 75V dc Input, 18V Input, 8W Power ATA02BB36-L
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters Artesyn / Advanced Energy ATA DC/DC Converter, 12V |
| Brand | Artesyn / Advanced Energy |
| Efficiency | 86% |
| Length | 23.8mm |
| Model | ATA02BB36-L |
| Depth | 8mm |
| Width | 13.7mm |
| Mount Type | Through Hole |
| Series | ATA |
| Maximum Operating Temperature | 80°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 2 |
| Maximum Output Power | 8W |
| Maximum Input Voltage | 75V dc |
| Minimum Input Voltage | 18V |
| Output Voltage 1 | 12, -12V |
| Output Current 1 | 335mA |
| Isolation Voltage | 1.5kV dc |
| Ultra-wide 4 | 1 input range |
Key Features
- It has an efficiency of up to 86%, ensuring energy-efficient operation.
- Designed with 1.5 kV DC isolation for enhanced safety and reliability.
- Compact dimensions of 23.8 x 13.7 x 8 mm allow space-saving design.
- Suitable for applications including industrial automation, telecommunication, and data communication.
- Compatible with remote On/Off control functionality for flexible operation.
- Designed for through-hole mounting with a mini dual-in-line package (DIP).
- Operational temperature range from -40°C to +80°C ensuring durability.
- Provides reliable voltage conversion for computer peripheral equipment.
Product Description
Artesyn / Advanced Energy ATA02BB36-L DC/DC Converter is designed for low-power electrical applications, delivering regulated dual outputs of 12V and -12V at 335 mA output current. This converter supports a wide input voltage range from 18V minimum to 75V maximum DC, with a continuous maximum output power of 8W. Packaged in a compact through-hole DIP form factor measuring 23.8 mm x 13.7 mm x 8 mm, it is ideal for industrial, telecommunications, data communication, and computer peripheral equipment power systems.
The converter offers high efficiency up to 86%, minimizing power loss and heat generation, while providing 1.5 kV DC input-to-output isolation for improved operational safety in sensitive circuits. Its ultra-wide 4:1 input voltage range adds versatility for varied power source environments, complemented by operational temperature tolerance from -40°C to +80°C for robust field performance.
Additional features include remote On/Off control for system integration flexibility and through-hole mounting compatibility that facilitates straightforward PCB assembly. The ATA02BB36-L is part of Artesyn's ATA series of DC/DC converters, known for reliable performance and consistent quality, backed by a three-year product warranty.
Ultra-wide input voltage range (18V to 75V DC). Output voltages of 12V and -12V at 335 mA output current. Maximum output power of 8W with 86% efficiency. 1.5 kV DC input-to-output isolation for enhanced safety. Compact through-hole DIP package for easy PCB mounting.
Operational temperature range from -40°C to +80°C. Remote On/Off control capability for flexible control. Suitable for industrial automation, data communication, telecommunications, and computer peripherals. Ultra-compact size 23.8 x 13.7 x 8 mm.
This series is widely used in industrial and commercial applications requiring reliable, compact DC/DC converters with robust performance. Explore more Artesyn / Advanced Energy DC/DC Converters at EnvMart for diverse power supply needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides dual outputs of 12V and -12V at a maximum output current of 335 mA.
It has an efficiency rating of up to 86%, which helps minimize power loss and heat generation during operation.
The input voltage range for this unit is from 18V to a maximum of 75V DC, providing versatility for various power source environments.
The dimensions of the ATA02BB36-L are 23.8 mm in length, 13.7 mm in width, and 8 mm in depth, making it compact for space-saving designs.
It features an isolation voltage of 1.5 kV DC, enhancing safety in sensitive circuits.
This unit operates within a temperature range of -40°C to +80°C, ensuring robust performance in various environments.
It is designed for through-hole mounting, which facilitates straightforward PCB assembly.
It is suitable for applications including industrial automation, telecommunications, data communication, and powering computer peripheral equipment.
Yes, the ATA02BB36-L is compatible with remote On/Off control functionality for flexible operation.
This model is part of the Artesyn ATA series of DC/DC converters, known for reliable performance.
The maximum output power of this converter is 8W, suitable for low-power electrical applications.
The country of origin for this model is Taiwan.
