MEAN WELL DDR-240B-24 DC/DC Converter 24V DC Output 10A, 16.8-33.6V DC Input, DIN Rail Mount 240W, -40°C to 70°C DDR-240B-24

MEAN WELL DDR-240B-24 DC/DC Converter is a highly reliable power supply solution designed for industrial and railway control systems. It delivers a stable 24V DC output at 10A from a wide input voltage range of 16.8V to 33.6V DC. The converter features a slim 40mm width DIN rail mountable housing with dimensions of 125.2mm width, 113.5mm depth, and 40mm length, facilitating compact and easy installation.

Engineered for harsh conditions, it operates efficiently between -40°C and 70°C and integrates a 4kV DC isolation voltage, enhancing electrical safety and minimizing interference. The unit delivers up to 240W of power at an efficiency of 90%, enabling robust performance with low energy loss.

This converter incorporates multiple protection mechanisms including short circuit, overload, over voltage, over temperature, input reverse polarity, and undervoltage protections to ensure longevity and safety. Its fanless design allows silent, maintenance-free operation while maintaining optimal temperatures through free air cooling.

The DDR-240B-24 supports adjustable output voltage, DC OK relay contact status signaling, and current sharing capabilities up to 150% peak load. It can be mounted on standard DIN rails TS-35/7.5 or 15, meeting several industry standards (EN61000 series, IEC60571, CE, and others) suitable for demanding industrial and railway environments.

This versatile DC/DC Converter is ideal for power supply applications in communication systems, security control, and industrial automation where reliable and stable voltage conversion is critical.

Designed for DIN rail mounting, ensuring easy installation and integration. Operates within a wide temperature range of -40°C to 70°C for harsh environments. Offers 240W maximum output power with high efficiency of 90%. Features 4kV DC isolation voltage for enhanced safety and noise reduction.

Includes comprehensive protection functions such as short circuit, overload, over voltage, over temperature, and reverse polarity protection. Supports adjustable output voltage and DC OK relay contact for monitoring. Fanless design allows for maintenance-free operation in confined spaces.
