MEAN WELL Medical Grade Switching Power Supply 48V DC, 65W, 264V AC Input, Chassis Mount MPM-65-48

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL Medical Grade Switching Power Supply 48V DC, 65W, 264V AC Input, Chassis Mount MPM-65-48

Name: MEAN WELL Medical Grade Switching Power Supply 48V DC, 65W, 264V AC Input, Chassis Mount MPM-65-48
Brand: MEAN WELL
SKU: 422090
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand MEAN WELL Condition New

Specifications

Country of Origin	China
Brand	MEAN WELL
Power	65W
Efficiency	92%
Length	87mm
Model	MPM-65-48
Depth	87mm
Gross Weight	191g
Width	52mm
Mount Type	Chassis
Series	MPM-65
Maximum Operating Temperature	80°C
Minimum Operating Temperature	-30°C
Number of outputs	1
Maximum Input Voltage	264V ac
Maximum Output Voltage	48V dc
SMPS Output Current	1.36A
Minimum Input Voltage	80V ac

Key Features

Supports input voltage range from 80V AC to 264V AC for versatile operation.
Output current is rated at 1.36A, suitable for medical applications.
Designed for operation between -30°C to 80°C with high thermal stability.
Compact dimensions of 87mm length, 52mm width, and 87mm depth for space-saving setup.
Achieves high efficiency of 92% to minimize energy loss during use.
Complies with multiple safety standards including UL 62368-1 and TUV BS EN 62368-1.
No minimum load required ensuring stable output under variable loads.
Extremely low leakage current enhances safety in sensitive environments.

Product Description

MEAN WELL MPM-65-48 is a medical grade switching power supply designed to provide reliable 48V DC output at 65W power with a chassis mount type. It supports a wide AC input voltage range from 80V to 264V, allowing flexible use in various environments. This power supply is engineered for high efficiency of 92%, reducing energy consumption and heat generation.

Operating temperature of -30°C to 80°C makes it suitable for demanding industrial and medical applications where thermal stability is critical. The compact form factor with 87mm length, 52mm width, and 87mm depth helps conserve installation space. Weighing only 191 grams, it is lightweight and convenient for system integration.

The MPM-65-48 model complies with stringent safety certifications such as UL 62368-1, TUV BS EN 62368-1, IS 13252 (Part 1), CSA C22.2 No. 62368-1, and others, ensuring safe and reliable operation in medical and industrial settings. It features extremely low leakage current and does not require a minimum load for stable output performance.

Designed for industrial, medical instrument, manufacturing, and laboratory power requirements, this switching power supply delivers consistent performance across a broad input range. Its chassis mount form factor facilitates easy mounting and integration into various electronic equipment.

Supports wide input voltage from 80V to 264V AC. Provides 48V DC output at 1.36A current. High operating temperature range from -30°C to 80°C. Compact chassis mount design with dimensions 87 x 52 x 87 mm. Highly efficient with 92% efficiency rate.

Certified for multiple international safety standards. Extremely low leakage current and no minimum load required. Lightweight design at 191 grams. Explore more power supply solutions in the Switching Power Supplies category on EnvMart to find the right product for your industrial and electronic needs.
