MEAN WELL High Density Medical Grade Switching Power Supply 24V DC Output, 90W Power, 80-264V AC Input, Chassis MPM-90-24

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL High Density Medical Grade Switching Power Supply 24V DC Output, 90W Power, 80-264V AC Input, Chassis MPM-90-24

Name: MEAN WELL High Density Medical Grade Switching Power Supply 24V DC Output, 90W Power, 80-264V AC Input, Chassis MPM-90-24
Brand: MEAN WELL
SKU: 422124
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand MEAN WELL Condition New

Specifications

Country of Origin	China
Brand	MEAN WELL
Power	90W
Efficiency	93%
Length	87mm
Model	MPM-90-24
Depth	87mm
Gross Weight	197g
Width	52mm
Mount Type	Chassis
Series	MPM-90
Maximum Operating Temperature	80°C
Minimum Operating Temperature	-30°C
Number of outputs	1
Maximum Input Voltage	264V ac
Maximum Output Voltage	24V dc
SMPS Output Current	3.75A
Minimum Input Voltage	80V ac

Key Features

Compact chassis mount design suitable for medical and industrial use.
Supports single output with 3.75A current capacity.
Operates efficiently with 93% efficiency to reduce energy loss.
Wide operating temperature range from -30°C to 80°C ensures reliable performance.
Has ultra-low no-load power consumption less than 0.1W.
Meets global safety and performance standards including UL 62368-1 and CSA C22.2.
Extremely low leakage current allows safe operation in sensitive environments.
Robust build with dimensions of 87mm x 87mm x 52mm and weighs 197 grams.

Product Description

MEAN WELL MPM-90-24 is a high density small size switching power supply specifically designed for medical grade applications. It provides a stable 24V DC output at 90W power capacity with a single output outputting 3.75A current.

This chassis mounted power supply supports a wide input voltage range from 80V AC up to 264V AC enabling global compatibility and stable operation. The unit maintains excellent efficiency of 93% minimizing energy wastage and heat generation.

Operating reliably in harsh environments, the power supply supports a minimum temperature of -30°C and a maximum of 80°C. It consumes less than 0.1 watts power when no load is applied, significantly reducing standby energy use.

Constructed with a compact form factor measuring 87mm in length and depth, and 52mm in width, it weighs only 197 grams. Safety is assured with certifications including UL 62368-1, CSA C22.2 No. 62368-1, TUV EN/EN 62368-1, and others ensuring compliance with major international standards.

Compact chassis mount design suitable for medical and industrial use. Supports single output with 3.75A current capacity. Operates efficiently with 93% efficiency to reduce energy loss. Wide operating temperature range from -30°C to 80°C ensures reliable performance.

Has ultra-low no-load power consumption less than 0.1W. Meets global safety and performance standards including UL 62368-1 and CSA C22.2. Extremely low leakage current allows safe operation in sensitive environments. Robust build with dimensions of 87mm x 87mm x 52mm and weighs 197 grams.

Supports input voltages from 80V AC minimum up to 264V AC maximum.

This switching power supply is ideal for industrial, medical equipment, laboratory instruments, manufacturing systems, and other professional applications requiring reliable DC power conversion from AC mains. Its compact size and wide input voltage range make it versatile for various power environments.
