MEAN WELL Switching Power Supply MPM-65-12ST 12V DC Output, 65W, 80-264V AC Input, High Efficiency 92.5% MPM-65-12ST

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL Switching Power Supply MPM-65-12ST 12V DC Output, 65W, 80-264V AC Input, High Efficiency 92.5% MPM-65-12ST

Name: MEAN WELL Switching Power Supply MPM-65-12ST 12V DC Output, 65W, 80-264V AC Input, High Efficiency 92.5% MPM-65-12ST
Brand: MEAN WELL
SKU: 422127
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand MEAN WELL Condition New

Specifications

Country of Origin	China
Brand	MEAN WELL
Power	65W
Efficiency	92.5%
Length	87mm
Model	MPM-65-12ST
Depth	87mm
Gross Weight	191g
Width	52mm
Mount Type	Chassis
Series	MPM-65
Maximum Operating Temperature	80°C
Minimum Operating Temperature	-30°C
Number of outputs	1
Maximum Input Voltage	264V ac
Maximum Output Voltage	12V dc
SMPS Output Current	5.42A
Minimum Input Voltage	80V ac

Key Features

High efficiency of 92.5% for maximum energy saving.
Single output with 5.42A current capacity.
Chassis mount type designed for reliable installation.
Operating temperature range from -30°C to 80°C suitable for various environments.
Compact dimensions 87mm length x 52mm width x 87mm depth.
Extremely low no-load power consumption less than 0.1W.
Compliance with multiple safety standards including UL, TUV, CSA and others.
Extremely low leakage current ensures safety in sensitive applications.

Product Description

MEAN WELL MPM-65-12ST is a high-density, small size switching power supply delivering 12V DC output with a power rating of 65W, capable of operating from 80 to 264V AC input voltage. This medical grade power supply features a chassis mount design and supports operating temperatures ranging from -30°C up to 80°C, making it suitable for demanding industrial, medical, laboratory, and commercial applications.

The power supply achieves an efficiency of 92.5%, greatly reducing energy loss during operation, while its extremely low no load power consumption below 0.1W helps minimize standby power consumption. It also features very low leakage current, enhancing safety for end-users and equipment.

Its compact dimensions of 87mm x 52mm x 87mm and a weight of 191g allow for easy integration into space-constrained systems. It supports a single output channel providing 5.42A of stable DC current at 12 volts.

This model complies with stringent international safety standards including UL 62368-1, TUV EN/IEC 62368-1, CSA, CCC, BSMI CNS, and AS/NZS certifications. It is designed to ensure reliable and safe operation in hazardous and sensitive areas but is not certified specifically for hazardous areas.

The MPM-65-12ST series power supply is ideal for use within industrial manufacturing, medical instrumentation, telecommunications, laboratory equipment, and other precision electronic devices demanding reliable power conversion with low losses.

High efficiency 92.5% reduces operational energy costs. Single output of 12V DC at 5.42A current. Chassis mounting for secure, stable installation. Wide input voltage range 80-264V AC for global compatibility. Compliance with multiple international safety approvals.

Extremely low no-load consumption less than 0.1W. Low leakage current enhances operational safety. Compact size and light weight facilitate easy integration.
