| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 1mm |
| Length | 3mm |
| Model | BAT54TA |
| Width | 1.4mm |
| Mount Type | Surface |
| Series | BAT54T |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 200mA |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 2μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 600mA |
| Maximum Forward Voltage Vf | 1V |
| Peak Reverse Recovery Time trr | 5ns |
DiodesZetex BAT54TA is a Schottky barrier switching diode designed for high reliability and thermal stability, making it suitable for industrial, automotive, and commercial electronic applications. This diode features a 3-pin SOT-23 surface-mount package that supports compact circuit board layouts and efficient production assembly.
Rated for a maximum continuous forward current of 200 mA and a peak reverse repetitive voltage of 30 V, the BAT54TA ensures robust performance in switching and rectification tasks. With a peak forward voltage of 1 V, this diode minimizes power loss and heat generation. Its fast switching capability with a reverse recovery time of 5 ns enables effective operation in high-frequency circuits, including power management and signal processing modules.
The device operates reliably over a broad temperature range from -65°C to 125°C and complies with the automotive industry standard AEC-Q101, underscoring its suitability for automotive electronic subsystems requiring stringent quality and durability.
The compact dimensions of 3 mm length, 1.4 mm width, and 1 mm height facilitate space-efficient PCB designs. The transient tolerant characteristics featuring a peak non-repetitive surge current of 600 mA improve the diode's ability to handle sudden current spikes, enhancing circuit protection.
Surface-mount SOT-23 package for small form factor designs. Single diode configuration optimized for switching applications. Low leakage current preserves circuit efficiency and battery life in portable devices. High thermal stability makes it suitable for harsh industrial environments.
Automotive-grade qualification with AEC-Q101 certification. Ideal for power supply rectification, voltage clamping, and signal demodulation. Reliable operation in consumer electronics, telecommunications, and automotive electronics.
This diode is an essential component for manufacturers and designers requiring a dependable switching diode solution with excellent thermal characteristics and compact packaging. Explore more semiconductor components on EnvMart for comprehensive industrial electronics needs.
