Vishay Bridge Rectifier, 100 V 300 A, 4-Pin Single KBU8B-E4/51

Free Delivery in India | Lowest Global Shipping Charges

Vishay Bridge Rectifier, 100 V 300 A, 4-Pin Single KBU8B-E4/51

Name: Vishay Bridge Rectifier, 100 V 300 A, 4-Pin Single KBU8B-E4/51
Brand: Vishay
SKU: 200963
Price: 4.36 USD
Availability: InStock



Category Bridge Rectifier Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	19.3mm
Length	23.7mm
Model	KBU8B-E4/51
Width	7.1mm
Mount Type	Through Hole
Series	KUB8
Configuration	Single
Maximum Operating Temperature	150°C
Package Type	KBU
Minimum Operating Temperature	-50°C
Number of Phases	1
Pin Count	4
Peak Reverse Repetitive Voltage Vrrm	100V
Peak Reverse Current Ir	10μA
Peak Non-Repetitive Forward Surge Current Ifsm	300A
Forward Current If	8A
Peak Forward Voltage Vf	1V
HY Electronic Corp Bridge Rectifier, 8A, 1000V, 4-PinBrand	HY Electronic Corp
Vishay Bridge Rectifier, 8A, 100V, 4-PinBrand	Vishay

Key Features

Supports forward current of 8 A for reliable performance.
Operates over temperature range from -50°C to 150°C.
Compact KBU package with dimensions 23.7 mm length, 19.3 mm height, and 7.1 mm width.
High surge current capability ensures durability under transient conditions.
Construction suitable for SIL PCB mounting with soldering pins for through-hole assembly.
Isolating voltage rating of 1500 Vrms for electrical safety.
Minimal forward voltage drop of 1 V enhances efficiency.
Peak reverse current of 10 μA ensures low leakage.

Product Description

Vishay KBU8B-E4/51 Bridge Rectifier is a high-performance semiconductor component engineered for converting alternating current (AC) input to direct current (DC) output in full-wave rectification applications. This 4-pin single-phase bridge rectifier device supports a peak reverse repetitive voltage of 100 V and a forward current of 8 A, with a peak non-repetitive forward surge current of 300 A.

The package type KBU provides a SIL (single inline) PCB mounting format with soldering pins designed for through-hole assembly, allowing easy and reliable installation on printed circuit boards. Its compact physical dimensions of 23.7 mm length, 19.3 mm height, and 7.1 mm width facilitate integration into space-constrained electronic assemblies.

Operating reliably across a temperature range from -50°C to 150°C, the Vishay KBU8B-E4/51 ensures durability and stability under varying thermal conditions. The device features an isolating voltage of 1500 Vrms for added electrical safety and a low peak forward voltage drop of 1 V to enhance overall circuit efficiency. Leakage currents are minimized with a peak reverse current of only 10 μA.

This rectifier is suitable for use in industrial, electronic semiconductor, power supply, and automotive applications requiring stable full-wave rectification and high surge current handling. While the device does not carry specific industry standards or automotive certifications, its robust design ensures dependable performance in typical Bridge Rectifier use cases.

Supports forward current of 8 A for reliable performance. Operates over temperature range from -50°C to 150°C. Compact KBU package with dimensions 23.7 mm length, 19.3 mm height, and 7.1 mm width. High surge current capability ensures durability under transient conditions.

Construction suitable for SIL PCB mounting with soldering pins for through-hole assembly. Isolating voltage rating of 1500 Vrms for electrical safety. Minimal forward voltage drop of 1 V enhances efficiency. Peak reverse current of 10 μA ensures low leakage.
