STMicroelectronics Schottky Diode 100 V 15 A Surface Mount TO-252 Package STPS15H100CB
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 2.4mm |
| Length | 6.6mm |
| Model | STPS15H100CB |
| Width | 6.2mm |
| Mount Type | Surface |
| Series | STPS15H100C |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 15A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Common Cathode |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 3μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 75A |
| Maximum Forward Voltage Vf | 0.62V |
Key Features
- Designed for surface mount applications with a TO-252 package type.
- Maximum continuous forward current rating of 15 A suitable for power applications.
- Peak reverse repetitive voltage of 100 V to handle high blocking voltages.
- Low maximum forward voltage drop of 0.62 V to improve efficiency.
- Operating temperature range from -65°C to 175°C for robust thermal performance.
- Common cathode diode configuration with 3 pins for easy circuit integration.
- Peak non-repetitive forward surge current of 75 A supports transient loads.
- Suitable for use in power supply, switching, and rectification circuits in industrial and electronic applications.
Product Description
STMicroelectronics STPS15H100CB is a high-performance Schottky diode designed for surface mount technology, packaged in a TO-252 (DPAK) single common cathode 3-pin configuration. It features a maximum continuous forward current of 15 amperes and a peak repetitive reverse voltage rating of 100 volts, making it suitable for demanding power rectification tasks. Its low forward voltage drop of 0.62 volts enhances power efficiency and reduces heat generation.
The diode offers a wide operating temperature range from -65°C to 175°C, allowing reliable operation in harsh industrial environments. It can withstand peak non-repetitive surge currents of up to 75 amperes, providing durability during transient events. The compact physical dimensions (6.6 mm length, 6.2 mm width, and 2.4 mm height) support dense PCB layouts in commercial electronic devices.
STPS15H100CB Schottky diode is widely used in power management circuits, switching power supplies, freewheeling diodes, and other applications requiring fast switching speed and low power dissipation. Its robust specifications and surface mount packaging simplify manufacturing and integration for industrial, laboratory, automotive (non-automotive standard), and commercial electronics sectors.
Designed for surface mount applications with a TO-252 package type. Maximum continuous forward current rating of 15 A suitable for power applications. Peak reverse repetitive voltage of 100 V to handle high blocking voltages.
Low maximum forward voltage drop of 0.62 V to improve efficiency. Operating temperature range from -65°C to 175°C for robust thermal performance. Common cathode diode configuration with 3 pins for easy circuit integration.
Peak non-repetitive forward surge current of 75 A supports transient loads. Compact dimensions: 6.6 mm length, 6.2 mm width, and 2.4 mm height for space-saving PCB design. Suitable for use in power supply, switching, and rectification circuits in industrial and electronic applications.
Explore more Schottky diodes & rectifiers at EnvMart for your semiconductor needs and engineering projects.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current rating of the STMicroelectronics Schottky Diode STPS15H100CB is 15 A.
This model has a peak reverse repetitive voltage rating of 100 V, suitable for handling high blocking voltages.
The operating temperature range for this diode is from -65°C to 175°C, allowing for reliable operation in harsh environments.
The maximum forward voltage drop of the STPS15H100CB is 0.62 V, which helps improve efficiency.
This diode features a common cathode configuration with 3 pins for easy circuit integration.
The physical dimensions of this diode are 6.6 mm in length, 6.2 mm in width, and 2.4 mm in height.
The peak non-repetitive forward surge current rating for this model is 75 A, supporting transient loads.
The STPS15H100CB is packaged in a TO-252 (DPAK) type, designed for surface mount applications.
This Schottky diode is suitable for use in power supply, switching, and rectification circuits in various industrial and electronic applications.
The peak reverse current for the STPS15H100CB is 3 μA.
This model belongs to the STPS15H100C series of Schottky diodes.
The country of origin for the STMicroelectronics Schottky Diode STPS15H100CB is India.
