Vishay Bridge Rectifier 800 V 250 A 4-Pin Through Hole KBU6K-E4/51

Free Delivery in India | Lowest Global Shipping Charges

Vishay Bridge Rectifier 800 V 250 A 4-Pin Through Hole KBU6K-E4/51

Name: Vishay Bridge Rectifier 800 V 250 A 4-Pin Through Hole KBU6K-E4/51
Brand: Vishay
SKU: 200962
Price: 5.2 USD
Availability: InStock



Category Bridge Rectifier Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	19.3mm
Length	23.7mm
Model	KBU6K-E4/51
Width	7.1mm
Mount Type	Through Hole
Series	KBU6
Configuration	Single
Maximum Operating Temperature	150°C
Package Type	KBU
Minimum Operating Temperature	-50°C
Number of Phases	1
Pin Count	4
Peak Reverse Repetitive Voltage Vrrm	800V
Peak Reverse Current Ir	5μA
Peak Non-Repetitive Forward Surge Current Ifsm	250A
Forward Current If	6A
Peak Forward Voltage Vf	1V
Bridge rectifier,KBU6K 6A 800VBrand	Vishay
Vishay Bridge Rectifier, 1000 V 250 A, 4-Pin SingleBrand	Vishay

Key Features

Engineered for through-hole mounting ensuring reliable PCB installation.
4-pin single-phase configuration for precise current conversion.
Operates effectively between -50°C and 150°C temperature range.
Features low peak forward voltage of 1 V minimizing power loss.
Offers high surge current capacity of 250 A for transient stability.
Peak reverse current at a minimal 5 μA for enhanced efficiency.
Designed without automotive standard certification, suitable for general electronic applications.
Isolating voltage capability of 1500 Vrms for safety in high voltage circuits.

Product Description

Vishay KBU6K-E4/51 Bridge Rectifier is a reliable electronic component engineered for full-wave rectification in power and semiconductor applications. Rated for peak reverse repetitive voltage of 800 V and a surge current capacity of 250 A, it efficiently converts AC input to DC output in single-phase circuits through its 4-pin configuration. Its through-hole KBU package allows secure mounting on printed circuit boards (PCBs), enhancing durability in various electrical devices.

This Bridge Rectifier operates across a wide thermal range from -50°C minimum to 150°C maximum, ensuring stability in diverse environmental conditions. With a peak forward voltage of 1 V and low peak reverse current of 5 μA, the unit exhibits excellent energy efficiency and minimal power loss during operation.

Its compact size with dimensions 23.7 mm (length), 7.1 mm (width), and 19.3 mm (height) allows integration into space-limited electronic assemblies. Although it does not hold automotive standard certification, it is well-suited for industrial, laboratory, electronic manufacturing, and power supply applications requiring robust rectification performance.

The device features a high isolating voltage of 1500 Vrms providing electrical insulation security in high voltage circuits. Its design includes soldering pins optimized for PCB through-hole mounting with a package center hole to aid in fixing and installation.

Engineered for through-hole PCB mounting for secure installation. Compact, reliable KBU package with 4-pin single phase configuration. Wide thermal operating range from -50°C to 150°C. High surge current capability of 250 A for transient durability.

Low forward voltage drop of 1 V improves efficiency. Minimal peak reverse current of 5 μA reduces leakage losses. Isolating voltage of 1500 Vrms offers electrical safety. Ideal for industrial electronics, power supplies, and lab equipment.
