Digital Magnetic Flow Meter 24VDC
Specifications
| Accuracy | for series AD 5% f.s. |
|---|---|
| Material | - Series AD EN 1.4404 (SS 316L)| aluminium| brass - Series VH EN 1.4404 (SS 316L)| PTFE |
| Operation | Vertical upwards flow (BD) - Horizontal flow left to right right to left |
| Flow switching | 1 reed switch (series AD & VH) - 2 reed switches (only series AD) - 1 or 2 inductive switches (only series AD) |
Key Features
- ? Machine or processes cooling ?? Hydraulic and lubrication circuits
- ??Thermal oil circuits ??Gas flow control ?? Mechanical fasteners cooling control
- Accuracy: ±5% full scale ??Scale range: according to flow rate chart on page 4 ??Scales in l/h, l/min, l/s, m3 /h, %, etc.
Product Description
Working principleA spring M keeps a disk B in zero flow rate position. When thefluid flows through the disk at a specific speed, a force is madeon the disk B, moving it to an equilibrium position.The distance covered by B depends on: - The force of the fluid flow F. - The relationship between areas A & B. - The force in opposition of the spring C.The equilibrium between forces F and the one generated by Cdefines the position of the disk B, equivalent to flow rate.The disk B, which contains a magnet M, acts over the switchesand/or the local indicator.Flow Switches and Indicator for Liquids and gasesMeasuring Range: 15 l/h 16000 l/h H2O300 Nl/h 130 Nm3/h air Accuracy:5% f.s.Connections: 2 BSPOthers on requestMaterials:Brass, Aluminum, EN 1.4404 (AISI316L)Options:4-20 mA analog output (only for ADI15+TH6)
- Fluid temperature: continuous 100ºC (max. allowable 120ºC) ??Working pressure: PN16 (others on request)
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The accuracy of this model is ±5% of full scale for the series AD.
It has a measuring range of 15 l/h to 16,000 l/h for water and 300 Nl/h to 130 Nm3/h for air.
The flow meter is made from brass, aluminum, and EN 1.4404 (AISI 316L).
It supports vertical upwards flow and horizontal flow from left to right or right to left.
The maximum continuous fluid temperature is 100ºC, with a maximum allowable temperature of 120ºC.
It can have 1 or 2 reed switches or 1 or 2 inductive switches, depending on the series AD.
The working pressure rating is PN16, with other ratings available upon request.
Yes, a 4-20 mA analog output is available, but only for the ADI15+TH6 configuration.
It operates by balancing the forces on a disk that moves in response to fluid flow, with the position of the disk indicating the flow rate.
Specific dimensions and weight details are not provided in the available data; please inquire for more information.
