General purpose Switch 400 Series

Name: General purpose Switch 400 Series
Brand: Potence
SKU: AAKXZ
Price: 7.87 USD
Availability: InStock



SKU AAKXZ Category General Switches Brand Potence Condition New

Specifications

Enclosure	Die cast aluminum\| epoxy powder coated\| gasketed\| captive cover screws
Weight	Approx. 3 to 7.5 lbs.\| varies with model
Vibration	Set point repeats after 2.5 G\| 5-500 Hz
Shock	Set point repeats after 15 G\| 10 millisecond duration
FILL	Temperature Models Non-toxic oil filled

Key Features

UL listed and cUL certified. FM approved. CE compliant to low voltage directive and pressure equipment directive
Optional ATEX or EAC intrinsic safety compliance. One, two or three switch outputs may be separated up to 100% of range.

Product Description

PRESSURE, VACUUM, DIFFERENTIAL PRESSUREAND TEMPERATURE SWITCHES The 400 Series is a versatile family of vacuum, pressure, differentialpressure and temperature switches for applications that require singleor multiple switching capabilities. Dual and triple switch versionsprovide multi-output for alarm and shutdown, pre-alarm and alarm,high/low limit or level staging functions.A wide variety of microswitch and process connection options,along with a weather-tight enclosure, make the 400 Seriesan ideal choice for most ordinary location applications. Itsworldwide use is assured with approvals and certifications toagency standards.Widely used throughout the process industries, the 400Series provides threshold protection and control for manycritical functions. Typical installations are found in industrialgas production, energy generation including pumps, turbinesand compressors, pulp and paper, and water and wastewatertreatment.A versatile vacuum switch, pressure switch, differential pressure, & temperature switch modelsUL, CSA, CE, FM-40 to 160F (-40 to 71C)Shock: Set point repeats after 15 G, 10 millisecond durationVibration: Set point repeats after 2.5 G, 5-500 Hz

Wide variety of available options and pressure sensor modules. Most models available for immediate delivery

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The weight of this model varies with the specific model, ranging from approximately 3 to 7.5 lbs.

This model is designed to operate under conditions of shock, repeating set points after 15 G for 10 milliseconds, and under vibration, with set points repeating after 2.5 G at frequencies of 5-500 Hz.

It is UL listed, cUL certified, FM approved, and CE compliant with low voltage and pressure equipment directives. Optional ATEX or EAC intrinsic safety compliance is also available.

The enclosure is made of die-cast aluminum, epoxy powder coated, and features gasketed captive cover screws for added protection.

Typical installations include industrial gas production, energy generation, pulp and paper processing, and water and wastewater treatment.

Yes, the 400 Series can be configured with one, two, or three switch outputs, which may be separated up to 100% of range for various functions.

This model operates effectively within a temperature range of -40 to 160°F (-40 to 71°C).

Installation requirements are not explicitly detailed, but the model features a weather-tight enclosure suitable for ordinary location applications.

The temperature models are non-toxic oil filled, which aids in their operation.

There is a wide variety of available options and pressure sensor modules for the 400 Series, allowing customization based on specific needs.

It provides threshold protection and control for many critical functions, making it widely used in various process industries.
