Vishay Bridge Rectifier 800 V 50 A 4-Pin Single, Through Hole Mount, DFM Package DF08M-E3/45

Vishay DF08M-E3/45 Bridge Rectifier is a discrete semiconductor device designed for reliable AC to DC conversion in electronic circuits through a full-wave rectification process. This 4-pin single bridge rectifier operates at a peak repetitive reverse voltage of 800 V and can handle forward currents up to 1 A, making it suitable for power supply and electronic control applications.

Its through-hole mount type and DFM package allow for easy integration into printed circuit boards with soldering pins intended for automated placement. The miniature glass passivated chip junction technology enhances device reliability and longevity, specially engineered for compact and efficient PCB designs.

Operating between -55°C to 150°C, this bridge rectifier is versatile for various industrial and commercial applications including power electronics, HVAC systems, instrumentation, and control units in manufacturing and automotive systems. The device's robust construction supports a peak forward surge current of 50 A, allowing it to manage transient high current events without damage.

The dimensions of 8.51 mm length, 6.5 mm width, and 3.3 mm height help maintain a minimal footprint on PCB layouts, enabling designers to optimize space in compact electronic assemblies. With a peak forward voltage drop of just 1.1 V and minimal reverse leakage current of 5 μA, the rectifier performs efficient power conversion while minimizing heat generation.

While there are no formal automotive standards applicable, this component complies with general electronic manufacturing standards for quality and reliability. It does not carry specific UL or other certification approvals but meets industry expectations for discrete semiconductor devices.

Designed for high surge current capability suitable for demanding applications. Miniature glass passivated chip junction ensures enhanced reliability. Operates within a temperature range from -55°C to 150°C for versatile use.

Equipped with four soldering pins for stable PCB through-hole mounting. Compact package size of 8.51 mm length and 6.5 mm width facilitates PCB space savings. Peak forward voltage of 1.1 V supports efficient power conversion.

Peak non-repetitive forward surge current rating of 50 A enables handling transient loads. Low peak reverse current of 5 μA minimizes leakage in circuits.

This Vishay bridge rectifier is ideal for industrial electronics, electronic instrumentation, power supply circuits, HVAC controls, and other electronic applications requiring robust and compact AC to DC conversion solutions. Explore the Bridge Rectifier category for related products at EnvMart.
