Nexperia Digital Transistor Dual Resistor Bias, 100 mA NPN + PNP, 50 V, 6-Pin UMT PUMD48,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Digital Transistor Dual Resistor Bias, 100 mA NPN + PNP, 50 V, 6-Pin UMT PUMD48,115

Name: Nexperia Digital Transistor Dual Resistor Bias, 100 mA NPN + PNP, 50 V, 6-Pin UMT PUMD48,115
Brand: Nexperia
SKU: 193895
Price: 0.06 USD
Availability: InStock



Category Digital Transistor Brand Nexperia Condition New

Specifications

Country of Origin	Malaysia
Brand	Nexperia
Height	1mm
Length	2.2mm
Model	PUMD48,115
Width	1.35mm
Mount Type	Surface
Series	PUMD48
Maximum Operating Temperature	150°C
Package Type	UMT
Minimum Operating Temperature	-65°C
Standards/Approvals	RoHS
Pin Count	6
Maximum Collector Emitter Voltage Vceo	50V
Minimum DC Current Gain hFE	80
Transistor Polarity	NPN + PNP
Maximum Emitter Base Voltage VEBO	10V
Maximum Collector Base Voltage VCBO	50V
Maximum Power Dissipation Pd	200mW
Maximum DC Collector Current Idc	100mA
Transistor Configuration	Isolated
Maximum Transition Frequency ft	180MHz

Key Features

The transistor has a 6-pin UMT surface mount package optimized for compact PCB applications.
It features integrated bias resistors allowing direct digital drive without external components.
The device supports a maximum power dissipation of 200 mW, suitable for low power switching.
Operating temperature range spans from -65°C to 150°C, ensuring reliability in harsh environments.
Maximum transition frequency is 180 MHz, suitable for high-speed switching circuits.
The minimum DC current gain (hFE) is 80, providing stable amplification characteristics.
Pin dimensions of 2.2 mm length, 1.35 mm width, and 1 mm height support miniaturized electronics.
The transistor polarity combines both NPN and PNP types in an isolated configuration for versatile circuit design.

Product Description

The Nexperia PUMD48,115 digital transistor integrates dual bias resistors with NPN and PNP configurations within a compact 6-pin UMT package. Designed for low power signal switching, it supports a maximum DC collector current of 100 mA and collector emitter voltage of 50 V, ideal for interfacing with digital control signals directly.

This device is surface mount type with an isolated transistor configuration, facilitating easy PCB assembly while minimizing external components due to its internal bias resistor design. Its 200 mW maximum power dissipation supports moderate switching applications in industrial and consumer electronics.

With a high minimum DC current gain of 80 and a maximum transition frequency of 180 MHz, the PUMD48,115 ensures fast response and reliable performance in digital circuits. It operates over a broad temperature range from -65°C to 150°C, suitable for demanding ambient environments including automotive and industrial installations.

Physical dimensions are compact at 2.2 mm length, 1.35 mm width, and 1 mm height, optimized for space-constrained applications on printed circuit boards. The transistor configuration is isolated NPN + PNP with integrated bias resistors.

Designed for use in industrial, communication, and computing electronic circuits requiring direct digital transistor drive. Its surface mount 6-pin UMT package enables automation-friendly assembly processes. The device is suitable for switching loads up to 100 mA at voltages reaching 50 V.

Applications include signal amplification, switching, and interfacing digital logic outputs to various load types. Explore EnvMart's comprehensive range of semiconductor devices, including bipolar and Digital Transistors, for diverse industrial and electronic design requirements.
