Molex 1 mm Pitch 16 Way Right Angle Female Easy-On FPC Connector Solder Termination 52271-1679

Molex 52271-1679 is a high-quality 16 way right angle female FPC connector with a 1 mm pitch, designed for surface mount technology (SMT) PCB applications. It features a Zero Insertion Force (ZIF) solder termination that minimizes wear and tear during repeated insertion cycles, enhancing reliability. The connector has a bottom contact position orientation, and its right angle design is optimized for space-saving PCB layouts in compact electronic devices.

This Easy-On series connector includes a slide type actuator that rotates 30°, facilitating easy and secure insertion of flexible printed circuits (FPCs). It provides consistent electrical contact retention even when cables are moved, ensuring stable signal transmission. The contact material is phosphor bronze plated with tin bismuth alloy, offering good electrical conductivity and corrosion resistance. The nylon housing delivers mechanical robustness and electrical insulation.

The connector supports electrical ratings up to 50 V AC and 500 mA current, making it suitable for signal and low power circuits. Its operational temperature range from -40°C to 85°C allows use in demanding industrial and automotive environments. The connector includes solder tabs providing additional mechanical support and strain relief on the PCB assembly, enhancing durability under mechanical stress.

Molex 52271-1679 connectors are extensively used in automotive navigation and audio systems, digital cameras, home security devices, tablets, notebooks, patient monitoring equipment, GPS receivers, smartphones, and other mobile communication devices. Their innovative design ensures secure and precise cable connection in tight packaging conditions.

Right angle female FPC connector with 16 contacts and 1 mm pitch. Zero Insertion Force (ZIF) solder termination reduces contact wear. Slide type actuator with 30° rotation for easy FPC insertion. Phosphor bronze contacts plated with tin bismuth alloy for conductivity.

Nylon housing material for insulation and durability. Rated for 500 mA current and 50 V AC voltage operation. Operating temperature range from -40°C to 85°C. Solder tabs provide secure PCB retention and strain relief. Locking mechanism ensures reliable connection stability.

This product is categorized under FPC Connectors in Electronics & Electricals, targeting applications in industrial, automotive, consumer electronics, and medical device manufacturing. Browse the Electronics Components category on EnvMart for related connectors and components.
