Vishay Bridge Rectifier 600 V 63 A 4-Pin Single VS-2KBP06

Free Delivery in India | Lowest Global Shipping Charges

Vishay Bridge Rectifier 600 V 63 A 4-Pin Single VS-2KBP06

Name: Vishay Bridge Rectifier 600 V 63 A 4-Pin Single VS-2KBP06
Brand: Vishay
SKU: 182930
Price: 2.02 USD
Availability: InStock



Category Bridge Rectifier Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	15mm
Length	17.5mm
Model	VS-2KBP06
Width	6.8mm
Mount Type	Through Hole
Series	VS-2KBP
Configuration	Single
Maximum Operating Temperature	150°C
Package Type	D-44
Minimum Operating Temperature	-40°C
Number of Phases	1
Pin Count	4
Peak Reverse Repetitive Voltage Vrrm	600V
Peak Reverse Current Ir	10μA
Peak Non-Repetitive Forward Surge Current Ifsm	63A
Forward Current If	2A
Peak Forward Voltage Vf	1V
Vishay Bridge Rectifier, 400 V 63 A, 4-Pin SingleBrand	Vishay

Key Features

The rectifier supports peak reverse repetitive voltage of 600 V for reliable performance.
Its forward current rating is 2 A, suitable for handling moderate electrical loads.
The device features a through-hole mount with a compact D-44 package type for easy PCB assembly.
It operates in a temperature range from -40 °C to 150 °C, offering stability under varying conditions.
High surge current capability up to 63 A peak non-repetitive forward surge current enhances transient handling.
The package dimensions measure 17.5 mm length, 15 mm height, and 6.8 mm width.
Peak forward voltage is low at 1 V, improving efficiency in rectification circuits.
Low peak reverse current of 10 μA ensures minimal leakage and reduced power loss.

Product Description

Vishay VS-2KBP06 Bridge Rectifier is a robust semiconductor device engineered for full-wave rectification in power supply and electronic circuits. This bridge rectifier converts AC input into DC output, ensuring consistent polarity regardless of input phase, making it ideal for industrial and consumer electronic equipment.

Built with four single diodes connected in a full bridge configuration, it accommodates a forward current of 2 A and a peak surge current of 63 A, supporting temporary overloads and transient conditions effectively.

Featuring a through-hole mount and compact D-44 package, it facilitates easy mounting on printed circuit boards, optimizing space without compromising performance.

The unit operates reliably within a temperature range from -40 °C to 150 °C and is rated for a peak reverse repetitive voltage of 600 V, suitable for a broad spectrum of low to medium power applications.

The bridge rectifier's minimal peak forward voltage of 1 V helps reduce heat generation, improving overall efficiency and longevity of the electronic systems it supports. The rectifier supports peak reverse repetitive voltage of 600 V for reliable performance.

Its forward current rating is 2 A, suitable for handling moderate electrical loads. It features through-hole mounting and a D-44 package type for durability and easy installation. Operational temperature range is from -40 °C to 150 °C for stability across environments.

High surge current capability up to 63 A enhances tolerance to power surges. Compact dimensions allow seamless integration into printed circuit boards. Low peak forward voltage of 1 V enhances conversion efficiency. Minimal peak reverse current of 10 μA reduces energy loss and leakage currents.

Part of the VS-2KBP series, renowned for reliability and compact construction. This bridge rectifier is widely applicable in industrial, consumer electronics, manufacturing, and electrical power conversion systems requiring efficient AC to DC conversion.

Its reliable performance ensures effective operation in power supplies, motor controls, and energy conversion units. Choose Vishay VS-2KBP06 for high-quality bridge rectification solutions optimized for diverse semiconductor applications.
