Vishay High Efficiency 600 V 40 A Standard Recovery Switching Diode 2-Pin DO-203AB VS-40HF60
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 17.4mm |
| Brand | Vishay |
| Height | 22.9mm |
| Length | 20.02mm |
| Model | VS-40HF60 |
| Width | 17.35mm |
| Mount Type | Screw |
| Series | VS-40HF |
| Maximum Operating Temperature | 190°C |
| Package Type | DO-203AB |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 40A |
| Peak Reverse Repetitive Voltage Vrrm | 600V |
| Diode Configuration | Stud Cathode |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 9mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 595A |
| Maximum Forward Voltage Vf | 1.3V |
| Vishay 400 V 40 A Diode Switching 2-Pin DO-203ABBrand | Vishay |
Key Features
- Designed for up to 40 amps continuous forward current.
- Peak reverse repetitive voltage rating of 600 volts.
- Standard recovery power diode in industry-standard 2-pin DO-203AB package.
- Supports a peak non-repetitive forward surge current of up to 595 amps.
- Maximum forward voltage drop of 1.3 volts for efficient switching.
- Operates reliably from -65°C to 190°C for wide thermal conditions.
- Compact dimensions approximately 22.9 mm height and 20.02 mm length.
- Stud cathode diode configuration with screw mount type ensuring secure installation.
Product Description
Vishay VS-40HF60 is a robust standard recovery switching diode that delivers a maximum continuous forward current of 40 amps at a reverse voltage of 600 volts. Packaged in the durable DO-203AB 2-pin housing with a stud cathode configuration and screw mount type, this diode is engineered for efficient and reliable operation.
This diode supports a peak non-repetitive forward surge current of 595 amps and features a maximum forward voltage drop of 1.3 volts, optimizing performance in high current switching environments. It reliably operates across a broad temperature range from -65°C to 190°C, making it suitable for demanding industrial and electronic component applications.
The compact physical dimensions of 22.9 mm height, 20.02 mm length, 17.35 mm width, and 17.4 mm diameter allow integration into various PCB and power control layouts. As a standard recovery rectifier diode, it serves well in power supplies, converters, and other semiconductor switching roles.
Designed for up to 40 amps continuous forward current. Peak reverse repetitive voltage rating of 600 volts. Standard recovery power diode in 2-pin DO-203AB package. Peak non-repetitive forward surge current of 595 amps. Maximum forward voltage of 1.3 volts to minimize power loss.
Operating temperature range from -65°C to 190°C. Compact and industry-standard mounting and dimensions. Low peak reverse current of 9 milliamps. Stud cathode configuration with secure screw mount. Suitable for industrial, laboratory, manufacturing, HVAC, and electronic use cases.
This product is ideal for power switching and rectification in industrial automation, HVAC systems, electronic design, and manufacturing assemblies. Vishay's semiconductor diodes ensure high reliability and performance, supported by broad application compatibility.
Explore more Vishay semiconductor products and switching diodes at EnvMart for advanced electronic component solutions.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the Vishay VS-40HF60 diode is 40 amps.
This model has a peak reverse repetitive voltage rating of 600 volts.
It operates reliably from -65°C to 190°C, making it suitable for a wide range of thermal conditions.
The maximum forward voltage drop for this diode is 1.3 volts, which helps minimize power loss during operation.
The diode supports a peak non-repetitive forward surge current of up to 595 amps.
The dimensions of the Vishay VS-40HF60 are approximately 22.9 mm in height, 20.02 mm in length, and 17.35 mm in width.
This model features a stud cathode configuration with a screw mount type for secure installation.
The diode configuration for this model is a stud cathode type.
The peak reverse current for the Vishay VS-40HF60 is 9 milliamps.
It is packaged in a standard 2-pin DO-203AB housing.
This diode is suitable for power switching and rectification in industrial automation, HVAC systems, and electronic design.
The Vishay VS-40HF60 diode is manufactured in India.
