Vishay 120 V 6 A Schottky Barrier Schottky DPAK Surface Mount TO-252 Package V6PWM12HM3/I
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Model | V6PWM12HM3/I |
| Mount Type | Surface |
| Series | eSMP |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 6A |
| Peak Reverse Repetitive Voltage Vrrm | 120V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100A |
| Maximum Forward Voltage Vf | 0.63V |
Key Features
- Utilizes Trench MOS Schottky technology for low forward voltage drop.
- Ideal for DC/DC converters, freewheeling diode, and polarity protection applications.
- Low profile design with typical height of 1.3 mm suitable for automated placement.
- Maximum forward voltage of 0.63 V ensures high efficiency operation.
- Wide operating temperature range from -40°C to 175°C for robust industrial use.
- Meets AEC-Q101 automotive standard and RoHS compliance.
- High surge current capacity of 100 A non-repetitive forward surge.
- Single diode configuration in reliable eSMP series packaging.
Product Description
Vishay V6PWM12HM3/I Schottky Barrier Schottky Diode is designed for high current density and low voltage applications requiring surface mount components with a low profile of 1.3 mm height. This device utilizes trench MOS Schottky technology to achieve very low forward voltage drop and power losses, making it suitable for high efficiency DC/DC converters, freewheeling diodes, and polarity protection circuits.
Its 120 V peak repetitive reverse voltage and 6 A maximum continuous forward current ratings provide reliable performance in demanding industrial, automotive, and power electronics environments. The diode features a maximum forward voltage of 0.63 V and can withstand non-repetitive peak surge currents up to 100 A, ensuring durability during transient events.
The surface mount TO-252 (DPAK) package facilitates automated placement on PCBs, improving production efficiency, and its compliance with automotive standard AEC-Q101 and RoHS regulations confirms its suitability for automotive and environmentally conscious applications.
The wide temperature operating range from -40°C to 175°C allows the diode to be deployed in harsh environments found in industrial and automotive systems. The single diode configuration in the eSMP series enhances integration flexibility in electronic circuit designs.
Trench MOS Schottky technology for low forward voltage and power loss. Compact, low profile TO-252 surface mount package for automated assembly. High efficiency operation in DC/DC converters and polarity protection. Wide operating temperature range (-40°C to 175°C) for demanding applications.
Meets AEC-Q101 automotive and RoHS compliance standards. High surge current capacity of 100 A peak non-repetitive forward surge. Single diode configuration, eSMP series.
This Vishay Schottky diode is ideal for industrial, automotive, electronic power supplies, and manufacturing applications requiring reliable, efficient rectification and protection solutions. Explore more components and solutions in our Semiconductor category at EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current rating of this model is 6 A.
This Schottky diode has a peak reverse repetitive voltage rating of 120 V.
The maximum forward voltage of this diode is 0.63 V.
It operates within a temperature range from -40°C to 175°C.
This model is packaged in a TO-252 (DPAK) surface mount configuration.
It meets the AEC-Q101 automotive standard.
The diode can withstand a peak non-repetitive forward surge current of 100 A.
This diode features a single diode configuration.
Yes, this model is RoHS compliant.
It is suitable for high efficiency DC/DC converters, freewheeling diodes, and polarity protection applications.
It utilizes trench MOS Schottky technology for low forward voltage drop.
The low profile design, with a typical height of 1.3 mm, facilitates automated placement on PCBs, improving production efficiency.
