Vishay 120 V 3 A Schottky Barrier Schottky 2-Pin DO-221AD Diode VSS8D3M12-M3/H
Specifications
| Country of Origin | China |
|---|---|
| Brand | Vishay |
| Height | 2.7mm |
| Length | 5mm |
| Model | VSS8D3M12-M3/H |
| Mount Type | Surface |
| Series | VSS8D3M12 |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-221AD |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 3A |
| Peak Reverse Repetitive Voltage Vrrm | 120V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Non-Repetitive Forward Surge Current Ifsm | 60A |
| Maximum Forward Voltage Vf | 0.61V |
Key Features
- Provides low forward voltage drop and fast switching speeds.
- Designed for high frequency inverters, DC/DC converters, and polarity protection.
- Compact DO-221AD package with 5 mm length and 2.7 mm height.
- Operates reliably from -40°C to 175°C operating temperature range.
- Automotive standard compliant with AEC-Q101 certification.
- Offers low leakage current and low power losses for efficient circuit operation.
- Ideal for industrial, commercial, and automotive applications.
Product Description
Vishay VSS8D3M12-M3/H is a Schottky Barrier Diode featuring a surface mount DO-221AD package designed for performance in demanding electronic applications. It delivers a maximum continuous forward current of 3 A and can withstand a peak reverse repetitive voltage of 120 V, making it suitable for power management tasks including high frequency inverters and DC/DC converters.
With a low forward voltage drop of 0.61 V, this diode minimizes energy losses and improves efficiency in electronic circuits. It includes a robust operating temperature range from -40°C to 175°C, ensuring stability under extreme environmental conditions.
This single configuration diode has two pins and is RoHS compliant, meeting environmental standards. The diode is automotive grade, certified to AEC-Q101 standards, demonstrating reliability for automotive electronics.
Its compact dimensions (length 5 mm, height 2.7 mm) facilitate easy PCB integration using automated placement methods. The diode exhibits low leakage current, reducing power dissipation in sensitive circuits.
Low forward voltage drop and fast switching speeds. Compact surface mount DO-221AD package. Wide operating temperature range from -40°C to 175°C. Automotive standard AEC-Q101 compliant. Low leakage current for energy-efficient circuits.
Robust single diode configuration with 2 pins. Suitable for industrial, commercial, and automotive applications.
Overall, the Vishay VSS8D3M12-M3/H diode is ideal for engineers designing power management solutions requiring high efficiency, thermal reliability, and automotive quality. Explore more semiconductor components on EnvMart to enhance your projects with quality Vishay products.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for the Vishay VSS8D3M12-M3/H Schottky diode is 3 A.
This model can withstand a peak reverse repetitive voltage of 120 V.
The maximum forward voltage drop for this diode is 0.61 V.
It operates reliably within a temperature range of -40°C to 175°C.
The diode is packaged in a compact DO-221AD surface mount package.
Yes, it is compliant with the AEC-Q101 automotive standard.
The dimensions are 5 mm in length and 2.7 mm in height.
This model features a single diode configuration with 2 pins.
The peak non-repetitive forward surge current is rated at 60 A.
It meets RoHS environmental standards.
It is suitable for high frequency inverters, DC/DC converters, and polarity protection in industrial, commercial, and automotive applications.
The diode exhibits low leakage current, which helps reduce power dissipation in sensitive circuits.
