Samtec QTH Series Right Angle Surface Mount Shrouded PCB Header 120 Contacts 0.5mm Pitch 2 Row QTH-060-03-L-D-A-TR

Samtec QTH-060-03-L-D-A-TR is a right angle surface mount PCB header with 120 gold or tin plated contacts spaced at a 0.5 mm pitch across two rows. The connector features a durable liquid crystal polymer housing that is shrouded to provide mechanical protection and proper alignment on the PCB. Its phosphor bronze contacts enable excellent conductivity and screwless solder termination secures reliable electrical connection.

This component supports a current rating of 2.2 amperes and functions efficiently within temperatures ranging from -55°C to 125°C, making it suitable for a wide range of demanding industrial and commercial electronic applications. It is typically used in board-to-board interface scenarios requiring high contact density in compact spaces.

The surface mount technology and right angle design facilitate low-profile assemblies, ideal for modern compact electronic devices, industrial controllers, and communication hardware. It does not conform to any specific approvals but meets standard industry quality norms.

Right angle orientation for board-to-board mating. 120 contact positions with 0.5 mm pitch in 2 rows. Liquid crystal polymer housing enhanced durability. Phosphor bronze contacts with gold or tin plating. Rated 2.2 A current handling capacity.

Operating temperature range: -55°C to 125°C. Surface mount solder termination type. Shrouded connector design adds protection.

This PCB header is suited for applications in electronic manufacturing, industrial automation, and telecommunications equipment. It offers reliable electrical connections and mechanical stability for complex PCB design requirements.
