Nexperia 4-Element Uni-Directional ESD Protection Diode, 200 W Peak Pulse Power, 6-Pin TSOP PESD3V3S4UD,115
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1mm |
| Length | 3.1mm |
| Model | PESD3V3S4UD,115 |
| Width | 1.7mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | TSOP |
| Minimum Operating Temperature | -65°C |
| Pin Count | 6 |
| Number of Elements per Chip | 4 |
| Clamping Voltage VC | 12V |
| Diode Configuration | Common Anode |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 5.3V |
| Maximum Reverse Stand-off Voltage Vwm | 3.3V |
| Peak Pulse Power Dissipation Pppm | 200W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 20A |
| Maximum Reverse Leakage Current | 800nA |
Key Features
- Features common anode diode configuration for reliable ESD suppression.
- Uni-directional direction type ensures precise transient voltage suppression.
- Supports a minimum breakdown voltage of 5.3 V for effective protection.
- Surface mount type with compact TSOP package for easy PCB integration.
- Maximum peak pulse current of 20 A accommodates high transient events.
- Clamping voltage of 12 V limits voltage spikes efficiently.
- Wide operating temperature range from -65°C to 150°C for industrial environments.
- Small dimensions of 3.1 mm length, 1.7 mm width, and 1 mm height optimize space usage.
Product Description
Nexperia PESD3V3S4UD,115 is a 4-element uni-directional electrostatic discharge (ESD) protection diode designed for safeguarding sensitive electronic components from voltage spikes and transient surges. Rated for a peak pulse power dissipation of 200 W, this diode ensures robust protection in environments where ESD events can damage semiconductor devices.
This device features a common anode diode configuration housed in a compact 6-pin TSOP surface mount package, making it suitable for modern compact PCB layouts in industrial, telecommunications, and automotive electronic systems. The uni-directional nature allows for predictable voltage suppression, protecting components downstream effectively.
With a minimum breakdown voltage of 5.3 V, maximum reverse stand-off voltage of 3.3 V, and a clamping voltage of 12 V, the diode effectively limits voltage spikes to safe levels. It supports a high maximum peak pulse current of 20 A, accommodating sudden high current transient events typical in ESD occurrences.
Designed for durability, the diode operates reliably over a temperature range from -65°C to 150°C, suitable for harsh environments often found in industrial and automotive applications. The small footprint dimensions of 3.1 mm length, 1.7 mm width, and 1 mm height ensure efficient use of PCB real estate.
Features common anode diode configuration for high reliability in ESD suppression. Uni-directional operation ensures consistent voltage clamping performance. Surface mount TSOP package facilitates automated assembly and space saving.
Supports heavy transient currents with 200 W peak pulse power rating. Wide operating temperature range suits demanding industrial conditions. Compact size enables integration into space-constrained circuit designs. Low maximum reverse leakage current of 800 nA minimizes power loss in normal conditions.
No automotive standard certification indicated; intended for general industrial electronic use.
The Nexperia PESD3V3S4UD,115 diode is ideal for protecting sensitive semiconductor devices in electronic circuits used in industrial, telecommunications, automotive, and equipment manufacturing sectors. It helps improve product reliability and longevity by preventing damage from electrostatic discharges and transient voltages.
Explore additional Nexperia ESD Protection Diode products and semiconductor components at EnvMart for comprehensive solutions tailored to your industrial and commercial electronic protection requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The PESD3V3S4UD,115 has a peak pulse power dissipation rating of 200 W, making it suitable for high transient events.
This model can accommodate a maximum peak pulse current of 20 A, which is essential for handling sudden high current transient events.
The clamping voltage of this diode is 12 V, which helps limit voltage spikes effectively during transient events.
The minimum breakdown voltage for the PESD3V3S4UD,115 is 5.3 V, ensuring effective protection against voltage spikes.
This diode has compact dimensions of 3.1 mm in length, 1.7 mm in width, and 1 mm in height, optimizing space usage on PCBs.
The PESD3V3S4UD,115 operates reliably over a temperature range from -65°C to 150°C, suitable for industrial environments.
This model utilizes a surface mount type, specifically in a compact TSOP package, facilitating easy PCB integration.
This diode features 4 elements per chip, designed for effective ESD protection.
The maximum reverse stand-off voltage for the PESD3V3S4UD,115 is 3.3 V, which is crucial for preventing breakdown during normal operation.
This diode features a common anode configuration, which enhances reliability in ESD suppression applications.
The maximum reverse leakage current for the PESD3V3S4UD,115 is 800 nA, which minimizes power loss under normal conditions.
This ESD protection diode is ideal for applications in industrial, telecommunications, automotive, and equipment manufacturing sectors.
