onsemi Bridge Rectifier GBPC3506W 600 V 400 A 4-Pin Single Through Hole GBPC Package

onsemi GBPC3506W Bridge Rectifier is a single-phase discrete semiconductor designed for high-power rectification in various industrial, electronic, and power applications. Engineered with a 4-pin through-hole GBPC package, it delivers a peak reverse voltage of 600 V and a forward current rating of 35 A, making it suitable for durability-demanding environments.

This bridge rectifier incorporates an integrally molded heatsink for enhanced thermal management, enabling very low thermal resistance and maximum heat dissipation. It supports peak non-repetitive forward surge currents up to 400 A, ensuring resilience to transient overload conditions.

The device operates safely within a temperature range from -55°C to 150°C, providing versatility across harsh operating environments. Its terminals are finished with silver for easy soldering in wire-type GBPC-W packages, ensuring reliable electrical connections.

With isolated case-to-lead voltage ratings exceeding 2500 V, the GBPC3506W effectively protects the circuitry from electrical interference and voltage spikes. Its compact dimensioning of 29 mm by 29 mm footprint with an 11.23 mm height facilitates efficient PCB layout in power supply designs.

Applications for this bridge rectifier include power supplies, motor controls, HVAC systems, and other industrial automation scenarios demanding high voltage and current rectification capabilities.

Operates at peak reverse repetitive voltage of 600 V. Rated for forward current of 35 A and surge current of 400 A. 4-pin single phase GBPC package with through-hole mount type. Max operating temperature up to 150°C and minimum operating temperature down to -55°C.

Silver-finished terminals optimized for soldering applications. Isolated case-to-lead voltage over 2500 V for robust circuit protection. Compact dimensions: 29 mm (L) x 29 mm (W) x 11.23 mm (H). Explore the onsemi Bridge Rectifier GBPC3506W and related semiconductor components for your electronics and industrial power needs on EnvMart.
