| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.01mm |
| Length | 3.04mm |
| Model | BSS138L |
| Width | 1.4mm |
| Mount Type | Surface |
| Series | BSS138L |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Channel Type | N |
| Maximum Continuous Drain Current Id | 200mA |
| Maximum Drain Source Voltage Vds | 50V |
| Maximum Drain Source Resistance Rds | 10Ω |
| Channel Mode | Enhancement |
| Maximum Power Dissipation Pd | 225mW |
| Typical Gate Charge Qg @ Vgs | 2.4nC |
| Maximum Gate Source Voltage Vgs | 20V |
| Forward Voltage Vf | 1.4V |
onsemi BSS138L is an N-Channel enhancement mode MOSFET designed for low voltage and low current switching applications. With a maximum continuous drain current of 200 mA and a drain-source voltage rating of 50 V, this device delivers reliable performance in compact surface mount configurations.
The device package is the miniature 3-pin SOT-23, enabling space-saving board layouts. The BSS138L MOSFET features a low forward voltage of 1.4 V and a maximum power dissipation of 225 mW, making it suitable for efficient power control.
Typical gate charge is 2.4 nC measured at gate-source voltage, allowing fast switching speeds required in DC-DC converters and power management modules. The device can operate continuously over a broad temperature range from -55°C to 150°C, ensuring durability in harsh industrial and automotive environments.
This MOSFET complies with the automotive AEC-Q101 standard, indicating robustness for use in automotive electronic systems. Its compact size and surface mount design make it favored for portable and battery-powered devices such as computers, printers, PCMCIA cards, cellular and cordless telephones.
Enhancement mode N-channel operation enables efficient switching. Compact 3-pin SOT-23 surface mount package saves board space. Supports 200 mA maximum continuous drain current. Rated for 50 V maximum drain-source voltage.
Low forward voltage of 1.4 V reduces power losses. Maximum power dissipation of 225 mW. Typical gate charge of 2.4 nC for fast switching. Wide operating temperature range from -55°C to 150°C. Automotive AEC-Q101 certified for automotive use.
Ideal for DC-DC converters and portable device power management.
Applications include industrial, automotive, consumer electronics, and telecommunications sectors. Use onsemi BSS138L for reliable signal amplification, switching, and energy-efficient power solutions.
