IXYS N-Channel IGBT Module 135 A 1200 V 7-Pin Y4-M5 Surface Mount MII100-12A3

IXYS MII100-12A3 is a high-performance N-Channel Insulated Gate Bipolar Transistor (IGBT) Module engineered for demanding power semiconductor applications. Rated for a continuous collector current of 135 A and a collector emitter voltage of 1200 V, this device supports high efficiency and rapid switching required in modern industrial electronics.

The module is housed in a 7-pin Y4-M5 package optimized for surface mounting, providing a compact footprint of 94 mm length, 34 mm width, and 30 mm height. The module's operating temperature range spans from -40°C to 150°C, ensuring reliable performance in harsh industrial environments.

The maximum power dissipation of 560 W enables robust thermal management during heavy loads. With a gate emitter voltage maximum of 20 V and switching speed capability up to 30 kHz, the IXYS MII100-12A3 module achieves efficient control with minimized conduction losses, thanks to a maximum collector emitter saturation voltage of 2.7 V.

This transistor module integrates the gate drive ease of MOSFETs and the high-current switching capability of bipolar transistors, making it ideal for power conversion, motor drives, inverters, and other industrial controls.

Maximum continuous collector current of 135 A delivers strong load capacity. High voltage rating of 1200 V ensures electrical reliability. Surface mount package supports compact and efficient PCB layouts. Wide operating temperature supports applications in diverse climates and conditions.

Low saturation voltage reduces power loss and improves module efficiency. Applicable across electronic, industrial automation, HVAC, and manufacturing sectors, the IXYS MII100-12A3 module is a reliable component for power semiconductor needs.
