Cosel DC/DC Converter PCB Mount 3.3V DC Output 7.5A 9-36V DC Input 24.75W Max Operating Temp 70°C STMGFS30243R3-N1

Cosel STMGFS30243R3-N1 is a high-quality DC/DC converter designed for industrial and electronic applications requiring reliable power conversions. It delivers a fixed 3.3V DC output at a current of up to 7.5A, powered by an input that ranges from 9V DC minimum up to 36V DC maximum. The unit features a PCB mounting type with compact dimensions of 117mm length, 52mm width, and 27mm depth, weighing 140g which makes it suitable for space-constrained electronic assemblies.

This converter benefits from built-in protections including overcurrent protection that automatically recovers and an optional overvoltage protection designed into specific series models like the STMG30. The output voltage can be finely adjusted within the range of 2.97V to 3.63V to meet sensitive load requirements.

Designed with an isolation voltage of 500V DC, it ensures operational safety and complies with numerous international certifications such as CE, EN, cUL, CSA, UL, and RoHS standards. The STMGFS series supports both convection and forced air cooling, maintaining performance across a temperature range from -70°C to 70°C.

With an efficiency rating of 89%, this converter minimizes energy loss and heat generation, making it a dependable solution in power supplies for industrial equipment, telecommunications, embedded systems, and laboratory instruments.

Isolated unit type DC-DC converter with cover provides robust protection. Wide input voltage DC range of 9-36 V suitable for varied power sources. Built-in automatic overcurrent protection enhances operational reliability.

Fine output voltage adjustment available for application flexibility. Compact PCB mount form factor with low weight adapts to tight spaces. High operational efficiency of 89% supports energy savings. Meets international standards including CE, UL, and RoHS for safety and compliance.

Wide operating temperature range allows usage in demanding environments. Isolation voltage of 500V DC enables safe integration into complex systems. Equipped with optional features like DIN rail attachments and connector interfaces.

The STMGFS30243R3-N1 DC/DC converter by Cosel is an excellent choice for industries requiring reliable, compact, and efficient power conversion modules. Environmentally robust with certifications and protective features, it fits applications in industrial automation, communications equipment, embedded electronics, and other precision-demanding fields. Browse EnvMart's extensive DC/DC Converter selection for complementary components and reliable power solutions.
