onsemi 30 V 1 A Surface Mount Schottky Diode 2-Pin DO-214AC MBRA130LT3G
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 2mm |
| Length | 4.32mm |
| Model | MBRA130LT3G |
| Width | 2.6mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 125°C |
| Package Type | DO-214AC |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 1mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 25A |
| Maximum Forward Voltage Vf | 410mV |
| Taiwan Semi 30V 1A, Schottky Diode, 2-Pin DO-214AC SS13 R3Brand | Taiwan Semiconductor |
Key Features
- This Schottky diode offers low forward voltage drop of 410 mV for high efficiency.
- It features high peak non-repetitive forward surge current of 25 A for transient tolerance.
- Operating temperature range from -55°C to 125°C makes it suitable for harsh environments.
- Compact 2 mm height, 4.32 mm length, and 2.6 mm width package size ideal for automated assembly.
- Pin count of 2 allows easy surface mounting in electronic circuits.
- Meets RoHS directives and is automotive qualified to AEC-Q101 standard.
- Suitable for low voltage, high frequency rectification, freewheeling, and polarity protection applications.
Product Description
onsemi MBRA130LT3G Schottky Diode is a 2-pin surface mounted power rectifier in a compact DO-214AC package, delivering 30 V peak reverse repetitive voltage and 1 A maximum continuous forward current. It features a low forward voltage drop of 410 mV and a peak surge current capacity of 25 A, allowing efficient and reliable operation in power management and signal rectification.
This diode is designed using the Schottky barrier principle that optimizes the forward voltage and reverse leakage balance, making it highly effective at high switching speeds and frequencies. Its epoxy molded lightweight package, measuring 2 mm height, 4.32 mm length, and 2.6 mm width, supports automated PCB assembly processes.
The component operates reliably across a wide temperature range from -55°C to 125°C, making it suitable for automotive and industrial environments. It complies with RoHS standards and is AEC-Q101 automotive qualified, ensuring quality and durability in critical applications.
Common industrial use cases include low voltage rectification in DC power supplies, freewheeling diode in motor control circuits, polarity protection diodes in automotive electronics, and other semiconductor applications requiring high speed and efficient switching.
This diode provides a compact and lightweight solution for power rectification. Its surface mount design ensures optimal board space utilization and automated assembly compatibility. High surge tolerance and low forward drop increase efficiency and device protection.
The product is compliant with environmental standards and automotive certifications. Ideal for industrial, automotive, laboratory, and commercial electronics applications. Choose onsemi Schottky Diodes & Rectifiers category to explore more semiconductor solutions designed for high performance and reliability.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 1 A.
This Schottky diode has a peak reverse repetitive voltage rating of 30 V.
The dimensions of the DO-214AC package are 2 mm in height, 4.32 mm in length, and 2.6 mm in width.
It operates within a temperature range of -55°C to 125°C.
The forward voltage drop is 410 mV.
The peak non-repetitive forward surge current rating is 25 A.
Yes, it is automotive qualified to the AEC-Q101 standard, making it suitable for automotive applications.
This diode complies with RoHS directives and is automotive qualified to AEC-Q101.
It supports surface mounting, making it suitable for automated assembly processes.
It is suitable for low voltage rectification, freewheeling, and polarity protection applications.
The peak reverse current is 1 mA.
The diode configuration is single, designed for efficient operation in various applications.
