Molex 0.5 mm Pitch 50 Way Vertical Male FPC Connector, Solder 501951-5000

Molex 501951-5000 0.5 mm Pitch 50 Way Vertical Male FPC Connector, Solder termination is a precision-engineered component designed for reliable, secure connections in compact electronic assemblies.

This connector features a fine 0.5 mm pitch with 50 contacts arranged in a single row, providing high-density interconnection capability in a small footprint.

Constructed with high-quality copper alloy contacts plated with tin bismuth over nickel, the connector offers excellent electrical conductivity and corrosion resistance. The housing is made from liquid crystal polymer, a robust material suited for demanding environments.

A hinged actuator mechanism allows for easy insertion and secure retention of FPC cables while enabling the connector contacts to move slightly with cable flexing, ensuring consistent contact force and signal integrity. The solder tabs on the base provide additional mechanical stability and strain relief on the PCB solder joints.

Electrical ratings include a current capacity of 400 mA per contact and a voltage rating of up to 50 volts AC. The device is rated for operating temperatures between -25°C and 85°C, accommodating a wide variety of industrial and consumer applications.

Its vertical orientation supports efficient PCB layout and assembly, often required in automotive navigation and audio systems, digital cameras, home security devices, tablet and notebook PCs, patient monitors, GPS units, smartphones, and tablets.

The connector’s compact design saves board space while maintaining performance. Its locking mechanism ensures stability of the connection even under vibration or mechanical stress. Suitable for solder mounting (SMT) to printed circuit boards for robust mechanical and electrical connection.

Widely used across automotive, consumer electronics, data communications, medical, and mobile phone industries. This high-quality Molex FPC Connector exemplifies precision manufacturing and is backed by stringent quality control as indicated by its origin from Japan.
