onsemi 50 V 1 A Fast Recovery Rectifier Diode DO-214AC 2-Pin RS1A
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 2.2mm |
| Length | 4.75mm |
| Model | RS1A |
| Width | 2.95mm |
| Mount Type | Surface |
| Series | RS1A - RS1M |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AC (SMA) |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | UL File No.: E326243 |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 50V |
| Diode Configuration | Single |
| Rectifier Type | Fast Recovery |
| Peak Reverse Current Ir | 50μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 30A |
| Maximum Forward Voltage Vf | 1.3V |
| Peak Reverse Recovery Time trr | 150ns |
| UL File No. | E326243 |
| Standards/ApprovalsUL File No. | E326243 |
Key Features
- Fast recovery diode suitable for power rectification.
- Maximum continuous forward current of 1 ampere.
- Peak reverse voltage rating of 50 volts.
- Low forward voltage drop of 1.3 volts for improved efficiency.
- Compact surface mount DO-214AC (SMA) package with 2 pins.
- Peak reverse recovery time of 150 nanoseconds for rapid switching.
- Operates reliably between -55°C and 150°C temperature range.
- Capable of withstanding 30 ampere peak surge current.
Product Description
onsemi RS1A is a high-performance fast recovery rectifier diode designed to provide efficient and reliable switching in electronic circuits. Packaged in a compact DO-214AC (SMA) 2-pin surface mount format, it supports a maximum continuous forward current of 1 ampere and offers a peak reverse voltage of 50 volts, making it ideal for power rectification tasks in electronics manufacturing and design.
The diode offers a low forward voltage drop of 1.3 volts, contributing to reduced power loss and heat generation. Its fast recovery time of 150 nanoseconds enables rapid switching operations, which are beneficial in switching power supplies, inverters, and other high-frequency applications.
Operational in a temperature range from -55°C up to 150°C, the RS1A diode is suitable for harsh environments encountered in industrial, automotive, and commercial electronics. It withstands peak non-repetitive forward surge currents of up to 30 amperes, which ensures robustness in transient conditions.
The device dimensions (length 4.75 mm, width 2.95 mm, height 2.2 mm) and surface-mount design simplify installation on PCB layouts, promoting automation and manufacturing efficiency. Certified to UL standards (File No. E326243), this diode meets stringent safety and quality benchmarks.
Fast recovery diode suitable for power rectification. Maximum continuous forward current of 1 ampere. Peak reverse voltage rating of 50 volts. Low forward voltage drop of 1.3 volts for improved efficiency. Compact surface mount DO-214AC (SMA) package with 2 pins.
Peak reverse recovery time of 150 nanoseconds for rapid switching. Operates reliably between -55°C and 150°C temperature range. Capable of withstanding 30 ampere peak surge current. Pin configuration and dimensions support easy PCB integration.
Compliance with UL standards (File No. E326243) ensures quality.
This product is extensively used in industrial electronics, power conversion equipment, automotive electronics, and consumer electronics for improved performance and reliability. Browse the Electronics & Electricals category at EnvMart for onsemi products and related semiconductor components.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the RS1A diode is 1 ampere.
The peak reverse voltage rating for the RS1A diode is 50 volts.
The forward voltage drop of this diode is 1.3 volts.
The peak reverse recovery time of the RS1A diode is 150 nanoseconds.
This model operates reliably between -55°C and 150°C.
The RS1A diode is packaged in a compact DO-214AC (SMA) surface mount format.
The dimensions of the RS1A diode are 4.75 mm in length, 2.95 mm in width, and 2.2 mm in height.
The RS1A diode can withstand a peak non-repetitive forward surge current of up to 30 amperes.
The RS1A diode has a pin configuration of 2 pins, suitable for surface mounting.
This diode is certified to UL standards, specifically UL File No. E326243.
The RS1A diode is extensively used in industrial electronics, power conversion equipment, automotive electronics, and consumer electronics.
The RS1A is classified as a fast recovery rectifier diode.
