DiodesZetex N-Channel MOSFET, 20 A Continuous Drain Current, 60 V Drain Source Voltage, Surface Mount, 3-Pin DMN6040SK3-13
Specifications
| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 2.39mm |
| Length | 6.7mm |
| Model | DMN6040SK3-13 |
| Width | 6.2mm |
| Mount Type | Surface |
| Series | DMN6040SK3 |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Channel Type | N |
| Maximum Continuous Drain Current Id | 20A |
| Maximum Drain Source Voltage Vds | 60V |
| Maximum Drain Source Resistance Rds | 50mΩ |
| Channel Mode | Enhancement |
| Maximum Power Dissipation Pd | 42W |
| Typical Gate Charge Qg @ Vgs | 22.4nC |
| Maximum Gate Source Voltage Vgs | -20, +20V |
| Forward Voltage Vf | -0.9V |
Key Features
- Supports enhancement mode operation for precise switching control.
- Maximum power dissipation rating of 42 W for high-efficiency thermal management.
- Low drain-source resistance of 50 mΩ reduces conduction losses.
- Operates reliably within a temperature range from -55°C to 150°C.
- Typical gate charge of 22.4 nC at gate-source voltage provides fast switching.
- Meets AEC-Q101 automotive standard ensuring robustness and reliability.
- Maximum gate-source voltage rating of ±20 V protects gate against voltage spikes.
- Forward voltage approximately -0.9 V for efficient operation.
Product Description
DiodesZetex DMN6040SK3-13 is an N-Channel MOSFET designed for surface mount applications requiring high efficiency and reliable performance. It supports a maximum continuous drain current of 20 A and a maximum drain-source voltage of 60 V, delivering robust power handling capability in a compact 3-pin TO-252 package.
This MOSFET operates using enhancement mode technology, ensuring precise switching behavior suitable for power management, automotive electronics, and industrial control circuits. It features a low on-resistance of 50 mΩ which minimizes conduction losses and supports power dissipation up to 42 W for effective thermal management.
Its maximum operating temperature of 150°C and minimum of -55°C make it suitable for harsh environments and demanding applications. The device includes a typical gate charge of 22.4 nC at a gate-source voltage of ±20 V, enabling fast switching speeds required in modern electronics.
Compliance with the AEC-Q101 automotive standard guarantees reliability and quality assurance for automotive system designs. The compact dimensions (6.7 mm length, 6.2 mm width, 2.39 mm height) make it ideal for space-constrained PCB layouts.
Common use cases for this MOSFET include industrial power circuits, automotive control units, DC-DC converters, motor drivers, and other semiconductor-based switching applications in electronics manufacturing, HVAC controls, and manufacturing equipment.
Enhancement mode N-Channel MOSFET for controlled switching. 20 A maximum drain current to handle substantial power loads. 60 V drain-source voltage rating for medium voltage applications. TO-252 surface-mount package suitable for automated assembly.
Low on-resistance enhances efficiency and reduces heat generation. AEC-Q101 qualification supports automotive usage and high reliability. Wide operating temperature from -55°C to 150°C ensures durability. Typical gate charge of 22.4 nC allows fast switching response.
Compact physical size for efficient PCB integration. Manufactured in China with strict quality controls. Explore the full range of MOSFETs and semiconductor components at EnvMart for your industrial and automotive applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous drain current for this model is 20 A.
It has a maximum drain-source voltage rating of 60 V.
The typical gate charge at gate-source voltage is 22.4 nC.
The on-resistance of this MOSFET is 50 mΩ, which helps reduce conduction losses.
This model operates reliably within a temperature range from -55°C to 150°C.
It comes in a TO-252 surface-mount package.
It meets the AEC-Q101 automotive standard, ensuring reliability for automotive applications.
The maximum power dissipation rating for this model is 42 W.
The dimensions are 6.7 mm in length, 6.2 mm in width, and 2.39 mm in height.
The forward voltage is approximately -0.9 V.
It features an enhancement mode N-channel configuration.
This model is suitable for applications such as industrial power circuits, automotive control units, and DC-DC converters.
