DiodesZetex 600 V 1 A General Purpose Schottky Diode 2-Pin DO-214AC S1J-13-F

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex 600 V 1 A General Purpose Schottky Diode 2-Pin DO-214AC S1J-13-F

Name: DiodesZetex 600 V 1 A General Purpose Schottky Diode 2-Pin DO-214AC S1J-13-F
Brand: DiodesZetex
SKU: 127651
Price: 0.06 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand DiodesZetex Condition New

Specifications

Country of Origin	India
Brand	DiodesZetex
Height	2.3mm
Length	4.6mm
Model	S1J-13-F
Width	2.92mm
Mount Type	Surface
Series	S1J
Maximum Operating Temperature	150°C
Package Type	DO-214AC
Minimum Operating Temperature	-65°C
Pin Count	2
Maximum Continuous Forward Current If	1A
Peak Reverse Repetitive Voltage Vrrm	600V
Diode Configuration	Single
Rectifier Type	General Purpose
Peak Reverse Current Ir	100μA
Peak Non-Repetitive Forward Surge Current Ifsm	30A
Maximum Forward Voltage Vf	1.1V
Peak Reverse Recovery Time trr	3μs
Vishay 600 V 1 A Diode General Purpose 2-Pin DO-214ACBrand	Vishay

Key Features

This diode is designed for surface mount applications with 2 pins in the DO-214AC package type.
It features a maximum continuous forward current of 1 ampere for reliable performance.
The peak reverse repetitive voltage rating is 600 volts, suitable for various power applications.
Peak reverse current is very low at 100 microamperes, improving efficiency.
The diode has a peak non-repetitive forward surge current rating of 30 amperes, providing transient robustness.
Maximum forward voltage drop is 1.1 volts, minimizing power loss in circuits.
Operating temperature range is wide, from -65°C to 150°C, for industrial applications.
Peak reverse recovery time is 3 microseconds, enabling fast switching speeds.

Product Description

The DiodesZetex S1J-13-F is a single configuration, general purpose Schottky diode designed for industrial and commercial electronic applications. It supports a maximum continuous forward current of 1 ampere and a peak reverse repetitive voltage of 600 volts. Its compact DO-214AC surface mount package with 2 pins makes it suitable for automated PCB assembly processes.

With a maximum forward voltage of 1.1 volts and low peak reverse current of 100 microamperes, this diode ensures low power loss and high efficiency in power rectification. Its peak non-repetitive forward surge current rating of 30 amperes provides durability against transient current spikes.

The operating temperature range spans from -65°C up to 150°C, making the S1J-13-F diode reliable in diverse environmental conditions. Its fast peak reverse recovery time of just 3 microseconds enables efficient switching in high-frequency circuits.

Physical dimensions are optimized for compact design: length of 4.6 mm, width of 2.92 mm, and height of 2.3 mm. This makes it highly compatible for space-constrained applications in power supply units, electronic converters, and other semiconductor systems.

This Schottky diode is ideal for power and general purpose rectification in industrial, commercial, and electronic component manufacturing. It offers stable operation in harsh temperature environments and rapid response times critical for high-efficiency power circuits.

Used widely in semiconductor assemblies for enhancing circuit reliability and performance. Its surface mount form factor fits modern electronics production lines for efficient soldering and layout. Explore a range of semiconductor components and Schottky diodes on EnvMart for your industrial and electronic design needs.
