Vishay 200 V 16 A Ultrafast Plastic Rectifier General Purpose 3-Pin D2PAK FESB16DT-E3/81
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 4.83mm |
| Length | 10.45mm |
| Model | FESB16DT-E3/81 |
| Width | 10.54mm |
| Mount Type | Surface |
| Series | FESB16xT |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-263 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 16A |
| Peak Reverse Repetitive Voltage Vrrm | 200V |
| Diode Configuration | Single |
| Rectifier Type | General Purpose |
| Peak Reverse Current Ir | 500μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 250A |
| Maximum Forward Voltage Vf | 975mV |
| Peak Reverse Recovery Time trr | 35ns |
Key Features
- Maximum continuous forward current of 16 A ensures high load handling.
- Peak reverse repetitive voltage rated at 200 V for reliable operation.
- Ultrafast recovery with peak reverse recovery time of 35 ns improves efficiency.
- Plastic TO-263 package type with surface mount for easy PCB integration.
- Operating temperature range from -65°C to 150°C ensures wide application flexibility.
- Forward voltage drop of 975 mV optimizes power efficiency.
- Complies with RoHS 2002/95/EC, WEEE 2002/96/EC, and UL 94V-0 standards.
- Automotive standard certified with AEC-Q101 qualification.
Product Description
Vishay FESB16DT-E3/81 is a high-performance ultrafast plastic rectifier designed for general purpose applications requiring efficient power conversion and reliability. It features a 200 V peak reverse repetitive voltage rating and supports a maximum continuous forward current of 16 A, making it suitable for demanding electronic circuits.
Its surface mount TO-263 plastic package enhances mechanical stability and facilitates automated assembly processes in manufacturing. The device offers fast recovery with a peak reverse recovery time of just 35 nanoseconds, significantly reducing switching losses and improving overall system efficiency.
Engineered for operation in harsh environments, it supports a wide temperature range from -65°C to 150°C, enabling its use in industrial, automotive, and power supply applications. The forward voltage drop of 975 mV balances conduction losses and thermal performance.
Vishay’s FESB16DT-E3/81 rectifier carries compliance certifications including RoHS, WEEE, and UL's 94V-0 flame retardancy, as well as automotive-grade AEC-Q101 approval, ensuring safe and reliable use in critical systems.
Maximum continuous forward current of 16 A ensures high load handling. Peak reverse repetitive voltage rated at 200 V for reliable operation. Ultrafast recovery with peak reverse recovery time of 35 ns improves efficiency.
Plastic TO-263 package type with surface mount for easy PCB integration. Operating temperature range from -65°C to 150°C ensures wide application flexibility. Forward voltage drop of 975 mV optimizes power efficiency. Complies with RoHS 2002/95/EC, WEEE 2002/96/EC, and UL 94V-0 standards.
Automotive standard certified with AEC-Q101 qualification. Peak non-repetitive forward surge current of 250 A for transient protection.
This rectifier is ideal for use in industrial electronics, power supply rectification, automotive electronics, and other commercial applications requiring robust discrete semiconductor components. Explore Vishay's range of semiconductor diodes and rectifiers for comprehensive solutions in power and signal conditioning. Browse more options in the Schottky Diodes & Rectifiers category at EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the FESB16DT-E3/81 is 16 A, ensuring high load handling capabilities.
This model has a peak reverse repetitive voltage rating of 200 V, providing reliable operation in various applications.
The peak reverse recovery time is 35 ns, which improves efficiency by reducing switching losses.
It operates within a temperature range of -65°C to 150°C, allowing for flexibility in various environmental conditions.
The FESB16DT-E3/81 comes in a TO-263 plastic package, designed for surface mounting to facilitate easy PCB integration.
The forward voltage drop is 975 mV, which optimizes power efficiency during operation.
This rectifier can handle a peak non-repetitive forward surge current of 250 A, providing transient protection.
It is certified with the automotive standard AEC-Q101, ensuring suitability for automotive applications.
The FESB16DT-E3/81 features a 3-pin configuration, suitable for various electronic circuit designs.
The dimensions are 10.45 mm in length, 10.54 mm in width, and 4.83 mm in height.
It complies with RoHS 2002/95/EC, WEEE 2002/96/EC, and UL 94V-0 standards, ensuring safe and reliable use.
This rectifier is designed for general purpose applications, including industrial electronics, power supply rectification, and automotive electronics.
