Molex 6-Way IDC Connector Male for Surface Mount, 1 Row, 1.2A, 250V ac, 1.27mm Pitch 90814-0806

Molex 90814-0806 is a 6-way IDC connector male designed for surface mount PCB applications, featuring a 1.27mm pitch and rated for 1.2A at 250 volts AC. It provides a compact and reliable wire-to-board connection solution suitable for high-density electronic assemblies.

The connector consists of a single row of six male contacts made from brass with tin over nickel plating, ensuring excellent corrosion resistance and conductivity. The housing is made from durable nylon, offering mechanical robustness and insulation properties.

Operating temperature range spans from -40°C to 105°C making it suitable for harsh industrial and automotive environments. The design includes friction lock, polarization, and stamped contacts with inline flat tabs for secure and proper mating.

This IDC connector series Picoflex is notable for its low profile with a mated height of only 6.4mm, saving significant space on PCBs compared to traditional connectors. It also provides high resistance to vibration and shock, essential for automotive and consumer electronics industries.

The product is manufactured in Ireland and complies with UL (E29179) and CSA (LR19980-181) safety standards, underlining its reliability and quality standards. Features 6 male contacts arranged in a single row for compact connection.

Supports a current rating of 1.2 amperes at 250 volts AC. Constructed with brass contacts plated in tin over nickel for corrosion resistance. Housing is made of durable nylon material for mechanical strength and insulation.

Suitable for surface mount PCB applications with straight orientation and IDC termination type. Operates reliably in temperatures ranging from -40°C to 105°C. Connector is unshrouded and includes friction lock and polarization features for secure mating.

Complies with UL and CSA approvals providing assurance of quality and safety. Manufactured in Ireland ensuring high standards of production. Ideal for automotive and consumer electronics requiring high-density, low profile connections.

This connector is ideal for industrial, automotive, consumer electronics, and high-density PCB designs where secure, vibration-resistant connections are critical. Explore further IDC Connectors and PCB component options on EnvMart for complete assembly solutions.
