Wurth Elektronik WE-TPC 6823 Shielded Wirewound Surface Mount Inductor with Ferrite Core 1 mH ±30% 160 mA 744062102
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Operating Temperature | - 40 to +125°C |
| Height | 2.3mm |
| Length | 6.8mm |
| Depth | 6.8mm |
| Packaging | Tape & Reel |
| Series | WE-TPC |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 1mH |
| Package/Case | 6823 |
| Maximum DC Current | 160mA |
| Maximum DC Resistance | 5Ω |
| Inductance Tolerance | ±30 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 2MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
| Standards/ApprovalsIEC 60286-3 | 2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, RoHS |
| IEC 60286-3 | 2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, RoHS |
Key Features
- Constructed with a ferrite core for effective magnetic performance.
- Magnetically shielded to minimize leakage fields during operation.
- Compact 6.8mm x 6.8mm x 2.3mm dimensions for surface mount applications.
- Operates reliably from -40°C up to 125°C temperature range.
- Compliant with automotive standard AEC-Q200 for enhanced durability.
- Offers a maximum DC resistance of 5 Ω ensuring efficient current flow.
- Designed for high frequency applications with a maximum self-resonant frequency of 2 MHz.
- Packaged in Tape & Reel format for automated assembly processes.
Product Description
Wurth Elektronik 744062102 WE-TPC series is a 6823 shielded wirewound surface mount inductor featuring a ferrite core, an inductance of 1 mH with ±30% tolerance, and a maximum DC current rating of 160 mA. This highly compact and flat power inductor measures 6.8mm in length and depth and 2.3mm in height, making it well suited for space-constrained surface mount applications.
The inductor is magnetically shielded, significantly reducing leakage magnetic fields and enhancing performance in sensitive circuit designs. It operates reliably within a wide temperature range from -40°C to 125°C, and its construction meets automotive standard AEC-Q200, assuring high reliability under demanding automotive and industrial conditions.
With a maximum DC resistance of 5 ohms and a maximum self-resonant frequency of 2 MHz, this component ensures efficient filtering and energy storage for high-frequency power switching circuits such as DC/DC converters, embedded PCs, and portable power devices including PDAs, digital cameras, and PCMCIA cards. The product is presented in a Tape & Reel package compatible with automated assembly lines and surface mount technology manufacturing.
Manufactured in China, the inductor complies with several international standards including IEC 60286-3:2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, and RoHS, ensuring material safety and performance consistency for industrial and commercial applications.
Constructed with ferrite core for magnetic efficiency. Magnetically shielded to reduce electromagnetic interference. Compact 6823 package dimensions enable dense PCB layouts. Wide operating temperature range supports automotive and industrial use.
Automotive standard AEC-Q200 certified for quality assurance. Low DC resistance optimizes current handling. High self-resonant frequency suitable for high-frequency circuits. Tape & Reel packaging ensures compatibility with SMT assembly.
Ideal for portable power, DC/DC converters, embedded systems, and telemetry. Meets international electrical and environmental standards.
Explore the Wurth Elektronik range for reliable, high-performance inductors suitable for demanding electronic applications. EnvMart offers extensive categories of electronic components and accessories engineered to industrial standards.
Explore more products in our Surface Mount Inductors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 1 mH with a tolerance of ±30%.
This model has a maximum DC current rating of 160 mA.
The dimensions of this inductor are 6.8mm in length, 6.8mm in depth, and 2.3mm in height.
It operates reliably within a temperature range of -40°C to 125°C.
This inductor is constructed with a ferrite core for effective magnetic performance.
The inductor is packaged in Tape & Reel format, which is compatible with automated assembly processes.
The maximum self-resonant frequency for this model is 2 MHz.
Yes, it is compliant with the automotive standard AEC-Q200, ensuring high reliability under demanding conditions.
The maximum DC resistance is 5 Ω, which ensures efficient current flow.
This inductor complies with several international standards including IEC 60286-3:2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, and RoHS.
It features a wirewound construction, which is typical for inductors designed for high-frequency applications.
This inductor is suitable for high-frequency power switching circuits such as DC/DC converters and portable power devices.
