Nexperia Digital Transistor 100 mA NPN 50 V 3-Pin SOT-23 PDTC114ET,215

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Digital Transistor 100 mA NPN 50 V 3-Pin SOT-23 PDTC114ET,215

Name: Nexperia Digital Transistor 100 mA NPN 50 V 3-Pin SOT-23 PDTC114ET,215
Brand: Nexperia
SKU: 121797
Price: 0.06 USD
Availability: InStock



Category Digital Transistor Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1.1mm
Length	3mm
Model	PDTC114ET,215
Width	2.5mm
Mount Type	Surface
Series	PDTC114E
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Standards/Approvals	RoHS
Pin Count	3
Maximum Collector Emitter Voltage Vceo	50V
Minimum DC Current Gain hFE	30
Transistor Polarity	NPN
Maximum Emitter Base Voltage VEBO	10V
Maximum Collector Base Voltage VCBO	50V
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	250mW
Maximum DC Collector Current Idc	100mA
Transistor Configuration	Single
Maximum Transition Frequency ft	230MHz
onsemi MMUN2211LT1G Digital Transistor, 50 V NPN Surface SOT-23, 3-PinBrand	onsemi

Key Features

Maximum DC collector current of 100 mA enables moderate switching currents.
Collector-emitter voltage up to 50 V for medium voltage operation.
Includes built-in resistors facilitating direct digital input drive.
Compact SOT-23 package with 3 pins allows surface mounting on PCBs.
NPN single transistor configuration for general purpose switching and amplification.
RoHS compliant and meets automotive AEC-Q101 standards.
Operates at frequency up to 230 MHz, suitable for high-speed applications.
Wide operating temperature range from -65°C to 150°C for reliability in harsh conditions.

Product Description

Nexperia PDTC114ET,215 digital transistor is a 3-pin NPN device designed for digital switching and amplification in electronic circuits. Housed in a compact SOT-23 surface mount package, this semiconductor device integrates resistors that enable easy interfacing directly with digital logic inputs.

With a maximum collector current of 100 mA and a collector-emitter voltage rating of 50 V, it suits many common applications requiring moderate current carrying capability and medium voltage operation. The device's power dissipation rating of 250 mW supports efficient thermal management in compact PCB layouts.

The transistor configuration is single NPN type, making it ideal for discrete switching functions as well as general amplification tasks. Its transition frequency up to 230 MHz supports applications in high-frequency signal environments.

Designed for robust performance, the device operates reliably across a broad temperature range from -65°C to 150°C, making it suitable for automotive, industrial, and consumer electronic applications. The product complies with RoHS standards and meets the automotive industry AEC-Q101 quality standard requirements, ensuring durability and compliance for demanding use cases.

Measuring just 3 mm in length, 2.5 mm in width, and 1.1 mm in height, the PDTC114ET,215 fits easily into densely packed circuit boards. Maximum collector current of 100 mA. Collector-emitter voltage 50 V rating. SOT-23 surface mount package type.

Single NPN digital transistor configuration. RoHS compliant and meets automotive AEC-Q101 standard. Operating temperature range -65°C to 150°C. 230 MHz maximum transition frequency. Power dissipation of 250 mW. Compact dimensions and pin count.

This digital transistor is widely used in electronics manufacturing, consumer electronics, automotive electronics, and industrial control systems where compact size, reliable digital switching, and efficient power handling are essential.
