Vishay 120 V 10 A Schottky Barrier Schottky DPAK Surface Mount Rectifier V10PW12HM3/I
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Model | V10PW12HM3/I |
| Mount Type | Surface |
| Series | eSMP |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | RoHS |
| Maximum Continuous Forward Current If | 10A |
| Peak Reverse Repetitive Voltage Vrrm | 120V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Non-Repetitive Forward Surge Current Ifsm | 180A |
| Maximum Forward Voltage Vf | 0.61V |
Key Features
- Utilizes Trench MOS Barrier Schottky technology for low forward voltage drop.
- Designed for low voltage, high frequency DC/DC converters and polarity protection.
- Surface mount TO-252 package with low profile of approximately 1.3 mm.
- Maximum forward voltage of 0.61 V ensuring efficient operation.
- Wide operating temperature range from -65°C to 150°C.
- Capable of handling peak non-repetitive forward surge current up to 180 A.
- Meets RoHS standards with automotive qualified ordering code available.
- Suitable for automated placement in high volume manufacturing.
Product Description
Vishay V10PW12HM3/I Schottky Barrier Schottky DPAK surface mount rectifier is engineered for efficient high-current applications handling up to 10 A continuous forward current at a maximum peak reverse voltage of 120 V. It features advanced Trench MOS Barrier Schottky technology delivering low forward voltage drop and low power losses, making it ideal for high frequency DC/DC converter circuits, freewheeling diode applications, and polarity protection.
The component is housed in a compact TO-252 package with a typical height of 1.3 mm, suited for surface mount technology (SMT) and automated manufacturing processes ensuring high efficiency and reliability in industrial, automotive, telecommunications, and power management systems.
The device supports a wide operating temperature range from -65°C to 150°C and can endure peak non-repetitive forward surge currents of up to 180 A, which provides robustness in transient conditions often encountered in switching applications. The rectifier is RoHS compliant and meets MSL level 1 per J-STD-020 for soldering resistance.
Standard features of this Vishay rectifier include low forward voltage drop (0.61 V max), single diode configuration, and no automotive standard except for specific automotive qualified ordering codes. It is part of the eSMP series.
Trench MOS Schottky technology for reduced conduction losses. Compact TO-252 surface mount package ideal for automated pick-and-place assembly. Wide ambient temperature operation from -65°C to +150°C. Peak surge current capability of 180 A enhances transient robustness.
Complies with environmental RoHS standards ensuring safety and sustainability. Common usage includes DC/DC converters, polarity protection, and freewheeling diode roles. Low profile and efficient thermal performance suitable for high density circuit boards.
Meets MSL level 1 with maximum soldering peak temperature of 260°C ensuring process reliability.
This product is ideal for industrial electronics, power management, telecommunications, automotive electronic control units, and other applications requiring efficient high-current rectification with compact form factor. Explore more Schottky diodes at EnvMart for advanced semiconductor solutions.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Vishay V10PW12HM3/I Schottky rectifier can handle a maximum continuous forward current of 10 A.
This model has a peak reverse repetitive voltage rating of 120 V.
The maximum forward voltage drop for this rectifier is 0.61 V.
It operates within a wide temperature range from -65°C to 150°C.
The rectifier is housed in a TO-252 surface mount package.
This model can handle peak non-repetitive forward surge currents of up to 180 A.
It features a single diode configuration.
Yes, the Vishay V10PW12HM3/I meets RoHS standards.
It is suitable for high-frequency DC/DC converters, polarity protection, and freewheeling diode applications.
It utilizes Trench MOS Barrier Schottky technology for low forward voltage drop and low power losses.
The TO-252 package has a typical height of approximately 1.3 mm.
The Vishay V10PW12HM3/I is manufactured in India.
