Vishay 60 V 20 A Schottky Diode Surface Mount 8-Pin FPAK V20KM60-M3/H
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 1.09mm |
| Length | 6.35mm |
| Model | V20KM60-M3/H |
| Width | 5.3mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 165°C |
| Package Type | FPAK |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 20A |
| Peak Reverse Repetitive Voltage Vrrm | 60V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 20mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 220A |
| Maximum Forward Voltage Vf | 0.65V |
Key Features
- The diode features low forward voltage drop of 0.39 V at 5 A, minimizing power loss.
- It includes Trench MOS Barrier Schottky technology for improved performance.
- Suitable for low voltage high frequency inverters, freewheeling, DC/DC converters, and polarity protection applications.
- Compact dimensions of 6.35 mm length, 5.3 mm width, and 1.09 mm height.
- Certified to meet RoHS and Automotive AEC-Q101 standards.
- Wide operating temperature range from -40°C to 165°C.
- Peak non-repetitive forward surge current is 220 A, supporting transient current spikes.
- Single diode configuration optimized for efficient switching.
Product Description
Vishay V20KM60-M3/H is a high current density Schottky diode in a surface mount 8-pin FPAK package designed for power electronics applications. Its maximum continuous forward current is 20 A with a peak reverse voltage of 60 V. This diode utilizes advanced Trench MOS Barrier Schottky (TMBS®) technology, providing ultra-low forward voltage drop of 0.39 V at 5 A, which reduces power dissipation and enhances efficiency.
The device’s compact size, with dimensions of 6.35 mm length, 5.3 mm width, and 1.09 mm height, makes it suitable for space-constrained circuit boards. It supports a wide operating temperature range from -40°C minimum to 165°C maximum, enabling reliable operation in harsh industrial environments.
Its single diode configuration is optimized for use in low voltage high frequency inverters, freewheeling diodes in power supplies, DC/DC converters, and polarity protection circuits. The peak non-repetitive forward surge current rating of 220 A allows it to withstand transient surges safely.
Adhering to RoHS compliance and Automotive AEC-Q101 standards, this diode assures quality and environmental safety for automotive and industrial applications.
Vishay's V20KM60-M3/H combines durable construction with high efficiency, suitable for industrial electronics, automotive power systems, manufacturing machinery, and other demanding electrical systems.
The diode features low forward voltage drop of 0.39 V at 5 A, minimizing power loss. Includes Trench MOS Barrier Schottky technology for better performance and efficiency. Compact 8-pin FPAK surface mount package ideal for high-density PCB layouts.
Wide temperature range from -40°C to 165°C ensures operation under extreme conditions. Meets RoHS compliance and automotive AEC-Q101 qualification standards. 220 A peak non-repetitive surge current rating provides robustness against transient surges.
Suitable for inverters, DC/DC converters, freewheeling, and polarity protection. Compact size enhances integration in power electronics and industrial controls. Explore the full Vishay diode range and suitable semiconductor components within EnvMart’s Electronics & Electricals category for efficient power conversion and control solutions.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this diode is 20 A.
The peak reverse voltage rating is 60 V.
This diode has dimensions of 6.35 mm in length, 5.3 mm in width, and 1.09 mm in height.
The operating temperature range is from -40°C to 165°C.
It complies with RoHS and Automotive AEC-Q101 standards.
The peak non-repetitive forward surge current rating is 220 A.
This diode uses an 8-pin FPAK surface mount package.
The forward voltage drop at 5 A is 0.39 V.
It is suitable for low voltage high frequency inverters, freewheeling, DC/DC converters, and polarity protection applications.
The rectifier type is Schottky.
The peak reverse current is 20 mA.
Yes, it features a single diode configuration optimized for efficient switching.
