| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 0.6mm |
| Length | 2.5mm |
| Model | PLZ5V1A-HG3_A/H |
| Mount Type | Surface |
| Series | PLZ |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-219AC (MicroSMF) |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 500mW |
| Diode Configuration | Single |
| Test Current It | 20mA |
| Maximum Reverse Leakage Current | 5μA |
| Nominal Zener Voltage Vz | 5.07V |
| Zener Type | General Purpose |
| Maximum Zener Impedance | 20Ω |
The Vishay PLZ5V1A-HG3_A/H is a high-precision 1.5 07 V Zener Diode designed for surface mount applications requiring excellent stability and low leakage currents. Rated for 500 mW maximum power dissipation, it comes in a low-profile DO-219AC (MicroSMF) package, making it suitable for compact electronic assemblies.
Operating across a wide temperature range from -55°C to 150°C, this Zener diode ensures consistent voltage regulation in harsh environments. It has a nominal Zener voltage of 5.07 volts, making it ideal for precision voltage referencing and protection circuits.
The device features a low reverse leakage current of 5 μA, and is tested at a current of 20 mA to guarantee performance reliability. Its maximum Zener impedance of 20 Ω enhances circuit stability, while the 2-pin configuration facilitates easy integration on printed circuit boards.
Compliant with RoHS, IEC 61760-1, IEC 61000-4-2 standards, and the automotive AEC-Q101 qualification, the PLZ Series diodes from Vishay are dependable for automotive and industrial electronic systems.
This diode is especially suited for use in industrial electronics, semiconductor assemblies, power management circuits, and automotive electronics where high reliability and stable voltage regulation are critical.
Nominal Zener voltage 5.07 V ensures precise voltage regulation. Maximum power dissipation of 500 mW supports moderate power applications. Surface mount DO-219AC (MicroSMF) package saves PCB space. Wide operating temperature range from -55°C to 150°C for versatility.
Low leakage current of 5 μA enhances device efficiency. Complies with automotive and international safety standards. 2-pin configuration simplifies PCB assembly and soldering. Ideal for automotive, industrial electronics, and semiconductor device use.
Explore more Vishay semiconductor components and find related Zener Diodes on EnvMart for robust and precise electronic designs.
