Wurth Elektronik Wirewound Surface Mount Inductor with Ferrite Core 22 μH ±30% 2.5 A Idc 744066220
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Operating Temperature | - 40 to +125°C |
| Height | 3.8mm |
| Length | 10mm |
| Depth | 10mm |
| Packaging | Tape & Reel |
| Series | WE-TPC |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 22μH |
| Package/Case | 1038 |
| Maximum DC Current | 2.5A |
| Maximum DC Resistance | 75mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 12MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
| Standards/ApprovalsIEC 60286-3 | 2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, RoHS |
| IEC 60286-3 | 2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, RoHS |
Key Features
- Features a ferrite core ensuring efficient magnetic shielding.
- Designed for surface mount applications using tape and reel packaging.
- Compact 10mm length, 3.8mm height, and 10mm depth dimensions.
- IEC compliant with robust operating temperature range from -40°C to 125°C.
- Supports AEC-Q200 automotive standard ensuring quality and reliability.
- Low maximum DC resistance of 75 mΩ for reduced power loss.
- Maximum self-resonant frequency of 12 MHz for stable performance.
- Suitable for use in portable power devices, DC/DC converters, and embedded PC systems.
Product Description
Wurth Elektronik 744066220 is a wirewound surface mount inductor with a ferrite core, designed for efficient power management in electronic devices. This 22 μH inductor offers a ±30% inductance tolerance and can handle a maximum DC current of 2.5 A, ensuring robust performance under demanding conditions.
The device features a shielded construction which reduces electromagnetic interference, making it ideal for integration into sensitive electronic circuits. Measuring 10 mm in length, 3.8 mm in height, and 10 mm in depth, it fits compactly on printed circuit boards using surface mount technology. Tape and reel packaging supports automated placement during manufacturing.
Compliance with standards such as IEC 60286-3:2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, and RoHS guarantee industry acceptance and environmental safety. The inductor is suitable for applications in portable power supplies, DC/DC converters, embedded PCs, and mobile data gathering and telemetric devices.
Features a ferrite core ensuring efficient magnetic shielding. Supports automotive grade AEC-Q200 standard for quality assurance. Wide operating temperature range from -40°C to 125°C for versatile applications. Low DC resistance of 75 mΩ minimizes power losses and heat generation.
Compact 10 mm size supports high-density PCB layouts. Maximum self-resonant frequency of 12 MHz ensures stability in high-frequency circuits. Magnetically shielded design reduces leakage fields and interference. Suitable for portable and embedded electronics requiring power inductors.
This Wurth Elektronik product is manufactured in China and is designed to meet stringent industrial requirements. Ideal for use in industrial electronics, telecommunications, automotive systems, and consumer electronic products.
Explore more Surface Mount Inductors and other electronic components suitable for your industrial and commercial requirements on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 22 μH with a tolerance of ±30%.
It can handle a maximum DC current of 2.5 A.
This inductor measures 10 mm in length, 3.8 mm in height, and 10 mm in depth.
The operating temperature range is from -40°C to +125°C.
The maximum self-resonant frequency is 12 MHz.
It features a ferrite core, which ensures efficient magnetic shielding.
This model is packaged in tape and reel format for automated placement during manufacturing.
It supports the AEC-Q200 automotive standard, ensuring quality and reliability.
The maximum DC resistance is 75 mΩ, which helps to minimize power loss.
It complies with IEC 60286-3:2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, and RoHS.
This inductor is constructed using a wirewound design.
It is suitable for applications in portable power devices, DC/DC converters, and embedded PC systems.
