Amphenol Communications Solutions EconoStik Series Right Angle Through Hole Pin Header 12 Contacts 2.54 10129382-912003BLF
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1500V |
| Brand | Amphenol Communications Solutions |
| Orientation | Right Angle |
| Current | 3A |
| Model | 10129382-912003BLF |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Brass |
| Series | EconoStik |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Mating Pin Length | 8.08mm |
Key Features
- Features 12 male contacts for versatile interconnections.
- Utilizes 2.54 mm pitch suitable for standard PCB layouts.
- Constructed with thermoplastic housing for high temperature resistance.
- Gold plated brass contacts ensure superior conductivity and corrosion resistance.
- Right angle orientation supports compact PCB designs.
- Through hole mount type ensures secure mechanical and electrical connection.
- Termination by solder for strong bond to PCB.
- Operating temperature range from -55°C to 105°C for industrial environments.
Product Description
Amphenol Communications Solutions 10129382-912003BLF EconoStik Series Right Angle Through Hole Pin Header features a high temperature thermoplastic housing and precision gold plating on brass contacts to provide excellent electrical performance and durability. This 12-contact pin header has a 2.54 mm pitch and a right angle orientation, suited for board-to-board applications requiring reliable connectors with solder termination.
Designed for industrial control systems, test equipment, metering devices, point-of-sale machines, set-top boxes, surveillance equipment, and vending machines, this pin header supports a wide range of electronic applications requiring dependable connectivity and mechanical stability.
The header's gold contact plating is tested to withstand up to 50 mating cycles, ensuring longevity in frequent connect/disconnect scenarios. The component complies with RoHS directives for environmental safety, featuring lead-free materials.
High temperature thermoplastic housing ensures performance in harsh environments. 1μin gold plating enhances contact reliability and reduces signal loss. Customized mating and tail lengths available for specific design requirements.
Unshrouded design facilitates easy inspection and soldering. Right angle orientation optimizes PCB real estate use. Rated for 1500V voltage and 3A current capacity. Reliable solder termination for secure electronic connection.
Suitable for diverse industrial and commercial electronic assembly applications. Package contents include one pin header with 12 contacts, packaged in a standard bag typically used for mass assembly processes. Explore additional PCB Headers and connectors at EnvMart to find components that match your assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pin header is rated for 1500V, making it suitable for various high-voltage applications.
This model has a current capacity of 3A, allowing it to handle a range of electrical loads.
The contacts have a pitch of 2.54 mm, which is standard for many PCB layouts.
It utilizes solder termination, ensuring a strong bond to the PCB for reliable connections.
The operating temperature range is from -55°C to 105°C, suitable for industrial environments.
This pin header features 12 male contacts, allowing for versatile interconnections.
The housing is constructed from thermoplastic, providing high temperature resistance.
It has a right angle orientation, which supports compact PCB designs and efficient use of space.
Yes, this component complies with RoHS directives, featuring lead-free materials for environmental safety.
The contacts are made of brass and are gold plated to enhance conductivity and corrosion resistance.
The gold contact plating is tested to withstand up to 50 mating cycles, ensuring longevity in frequent connect/disconnect scenarios.
It features a through hole mount type, ensuring a secure mechanical and electrical connection to the PCB.
