| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 0.6mm |
| Length | 2.5mm |
| Model | PLZ2V0B-HG3_A/H |
| Mount Type | Surface |
| Series | PLZ |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-219AC (MicroSMF) |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 500mW |
| Diode Configuration | Single |
| Test Current It | 20mA |
| Maximum Reverse Leakage Current | 120μA |
| Nominal Zener Voltage Vz | 2.2V |
| Zener Type | General Purpose |
| Maximum Zener Impedance | 140Ω |
The Vishay PLZ2V0B-HG3_A/H is a compact surface-mount Zener diode engineered for high reliability and consistent voltage regulation in automotive and general electronics applications. With a nominal Zener voltage of 2.2V and a maximum power dissipation of 500mW, this device supports circuits requiring voltage stabilization and overvoltage protection in demanding environments.
Encased in a space-efficient DO-219AC (MicroSMF) package, the diode features a single zener element and a 2-pin configuration, enabling straightforward integration onto modern PCBs via standard SMT processes such as wave and reflow soldering. Its low profile (2.5mm length, 0.6mm height) allows for use in densely populated assemblies or height-restricted modules.
Nominal Zener voltage of 2.2V with a tightly controlled tolerance ensures reliable clamping and voltage reference. 500mW power handling capability supports buffer, filter, and protection functions in power-sensitive designs.
Low leakage current and stable thermal characteristics boost circuit reliability across a wide operational spectrum. Maximum Zener impedance of 140Ω and reverse leakage current capped at 120μA contribute to consistent device performance.
Compliant with IEC 61000-4-2, IEC 61760-1, RoHS directives, and meets the rigorous AEC-Q101 automotive standard for enhanced durability. Operating across -55°C to +150°C, the diode is ideal for harsh automotive, industrial, or telecommunications environments.
Surface mountable DO-219AC package optimizes automated manufacturing efficiency and design flexibility.
This Zener diode is utilized for voltage regulation, protection against transient voltages, and as a precise voltage reference in control circuits, instrumentation, and automotive electronic control units. Its high reliability and compact form make it a top choice for industrial, automotive, and commercial control system manufacturers.
Explore more Zener Diodes, voltage clamps, and circuit protection solutions from Vishay and top semiconductor brands on EnvMart to meet your application-specific requirements.
