Hirose DF13 Series Straight Surface PCB Header, 5 Contacts, 1.25 mm Pitch, 1 Row, Shrouded

Hirose DF13C-5P-1.25V(51) Straight Surface PCB Header is a compact and reliable electronic connector designed with five contacts arranged in a single row with a 1.25 mm pitch. This shrouded header features a compact footprint, making it ideal for applications requiring space saving without sacrificing performance.

The header is crafted with a durable polyamide housing that ensures insulation and mechanical protection. The copper alloy contacts are plated with gold, enhancing conductivity and preventing oxidation, which guarantees a stable electrical connection over the product's lifecycle. The connector supports a maximum current of 1 amp and voltage up to 150 volts, making it suitable for a variety of low-power electronic applications.

The shrouded design incorporates polarization slots and a scoop proof box structure to prevent incorrect insertions and provide easy alignment during mating. Surface mount technology (SMT) style mounting allows for effective soldering to the PCB, with metal fittings enhancing attachment strength and resistance to solder peeling.

This PCB header includes PCB mounting bosses which aid in accurate positioning during assembly, contributing to improved reliability of the PCB connections. The design also supports automated pick-and-place manufacturing methods thanks to vacuum pickup areas and tape-and-reel packaging options.

Compact and space-saving connector solution for printed circuit boards. Shrouded housing with polarization features for error-proof mating. Gold-plated copper alloy contacts ensuring conductivity and corrosion resistance.

Surface mount type with metal fittings for secure PCB attachment. Operational temperature range from -35°C to 85°C suitable for diverse environments. Friction locking mechanism guarantees a secure connection with mating housing.

Ideal for portable electronics including cameras, displays, and access control units. PCB mounting bosses facilitate precise assembly on circuit boards. Enables automated placement with vacuum pickup compatible versions.

This Hirose DF13 series connector is highly suited for industrial and laboratory electronics manufacturing, digital device assembly, and commercial electronic equipment production. It provides a reliable wire-to-board connection solution combining compact dimensions, secure mating, and robust contact materials. Browse our Electronics Components category on EnvMart for more Hirose connectors and related products.
