Hirose 0.3 mm Pitch 80 Way Straight Female ZIF Bottom Contact FPC Connector FH30

Free Delivery in India | Lowest Global Shipping Charges

Hirose 0.3 mm Pitch 80 Way Straight Female ZIF Bottom Contact FPC Connector FH30

Name: Hirose 0.3 mm Pitch 80 Way Straight Female ZIF Bottom Contact FPC Connector FH30
Brand: Hirose
SKU: 204795
Price: 20.22 USD
Availability: InStock



Category Connectors Brand Hirose Condition New

Specifications

Country of Origin	India
Voltage	50V ac
Brand	Hirose
Orientation	Straight
Current	150mA
Model	FH30
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	FH30
Termination Type	ZIF Bottom Contact
Maximum Operating Temperature	85°C
Sub Type	FPC
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	0.3mm
Contact Plating	Gold
Number of Contacts	80
Contact Gender	Female
Connector Gender	Female
Insertion Force	ZIF
Contact Position	Bottom

Key Features

Features 80 contacts with 0.3 mm pitch for high density.
Constructed with phosphor bronze contacts plated in gold for durability.
Zero insertion force (ZIF) bottom contact termination ensures easy cable insertion.
Includes a rotating flip-lock actuator for secure locking and retention.
Supports a current rating of 150mA and voltage up to 50V AC.
Operating temperature ranges from -40°C to 85°C for robust performance.
Housing made from liquid crystal polymer offering strength and insulation.
Designed with a low profile 3.00 mm height and straight orientation for space-saving designs.

Product Description

Hirose FH30 model 0.3 mm Pitch 80 Way Straight Female ZIF Bottom Contact FPC Connector is engineered for compact, high-density electronic applications. This connector is tailored for Zero Insertion Force (ZIF) cable attachments, ensuring damage-free and simple FPC (Flexible Printed Circuit) insertion.

Constructed with phosphor bronze contact material and gold plating, it guarantees reliable conductivity and corrosion resistance. The connector features a robust rotating flip-lock actuator that securely locks the flat flexible cable in place, yielding a tactile click upon full engagement to ensure confidence during assembly and operation.

Rated for a current of 150mA and a voltage tolerance of 50V AC, the FH30 is suitable for low power electronic devices. It operates efficiently across a wide temperature range of -40°C to 85°C, making it suitable for demanding industrial and commercial environments.

The housing is made from liquid crystal polymer, imparting durability and electrical insulation. This connector's low profile design with a height of 3.00 mm aligns with space-constrained applications such as mobile phones, digital video cameras, PDAs, and LCD displays. The connector's bottom contact position and straight orientation simplify PCB layout and soldering processes.

80 contacts with 0.3 mm pitch enable high-density connections in restricted spaces. Phosphor bronze contact material with gold plating delivers long-lasting electrical performance. Rotating flip-lock ZIF actuator facilitates easy cable insertion and secure locking.

Surface mount design supports straightforward PCB assembly. Capable of operating between -40°C and 85°C for versatile applications. Low 3.00 mm profile height suits compact electronic designs. Halogen free as per IEC61249-2-21 standards, supporting environmental compliance.

Suitable for electronic, industrial, telecommunications, and consumer electronics uses.

This connector is ideal for industries requiring reliable PCB connector solutions with easy, damage-free FPC insertion and robust mechanical retention. EnvMart offers this genuine Hirose FH30 series connector for manufacturing, repair, and R&D projects in electronics.
