STMicroelectronics 1 kB Serial EEPROM 200 ns 8-Pin TSSOP Serial-Microwire M93C46-WDW6TP

STMicroelectronics M93C46-WDW6TP is a 1 kB Serial EEPROM offering fast 200 ns access time and reliable serial data storage in an 8-pin TSSOP package. It utilizes the industry standard MICROWIRE serial communication interface, allowing seamless integration with compatible microcontrollers and systems.

This EEPROM device operates at a maximum clock frequency of 2 MHz and supports a voltage range from 2.5 V minimum to 5.5 V maximum, providing flexibility across various embedded and automotive applications. It is designed to work under extreme conditions with an operating temperature range of -40°C to 85°C.

With a supply current of just 1 mA, the M93C46-WDW6TP ensures low power consumption, ideal for battery-powered devices. It offers data retention for up to 200 years, ensuring long-lasting memory preservation.

The device complies with the automotive standard AEC-Q100, making it suitable for automotive electronics requiring high reliability. It comes in a small outline TSSOP surface-mount package with dimensions of 3.1 mm length, 6.4 mm width, and 1.2 mm height, optimizing PCB space usage.

Memory size: 1 kB. Serial-Microwire interface type. 8-pin TSSOP package. Maximum clock frequency 2 MHz. Operating voltage 2.5 V to 5.5 V. Operating temperature -40°C to 85°C. Low supply current 1 mA. Data retention 200 years.

Automotive standard AEC-Q100 compliance. Package dimensions: 3.1 mm x 6.4 mm x 1.2 mm.

This serial EEPROM is ideal for industrial, automotive, and embedded systems applications requiring efficient and dependable non-volatile memory storage. Its compact form factor and standard interface support ease of integration into circuit designs.
