DiodesZetex N-Channel MOSFET 30 V 4 A 3-Pin SOT-23 Surface Mount Enhancement Type DMG3402L-7

DiodesZetex DMG3402L-7 is a Type N-Channel MOSFET transistor designed for surface mount applications in electronic circuits requiring low voltage switching and amplification. It is housed in a compact 3-pin SOT-23 package ideal for automated surface mounting on printed circuit boards. This MOSFET features a maximum drain-source voltage rating of 30 V and a continuous drain current capacity of 4 A, making it suitable for handling moderate power loads efficiently.

Operating at enhancement mode, the DMG3402L-7 delivers low conduction losses with a maximum drain-source resistance (Rds) of 85 milliohms. It also supports a maximum gate-source voltage of 12 V with a typical gate charge of 11.7 nanocoulombs, enabling fast switching performance ideal for power management applications. The device is capable of dissipating up to 1.4 W of power, with operating temperature tolerances ranging from -55°C to 150°C, ensuring robust performance across demanding environmental conditions.

Compliant with automotive quality standards AEC-Q100, AEC-Q200, and AEC-Q101, this MOSFET is well-suited for automotive electronics, industrial controls, consumer devices, and other electronic equipment requiring durable semiconductor components. Its small physical footprint dimensions - 3 mm length, 1.4 mm width, and 1 mm height - support space-saving designs in dense electronic assemblies.

Compact 3-pin SOT-23 package suitable for surface mount technology. Enhancement mode N-Channel operation for efficient switching. Maximum continuous drain current of 4 A at 30 V rating. Low maximum drain-source resistance of 85 milliohms ensures minimal conduction losses.

Power dissipation capacity of 1.4 W supports moderate power loads. Wide operating temperature range from -55°C to 150°C for reliability. Typical gate charge of 11.7 nC allows fast switching. Complies with automotive standards for high-quality assurance.

This DiodesZetex MOSFET DMG3402L-7 is an excellent choice for industrial, automotive, and consumer electronics requiring efficient low voltage switching components. EnvMart users can confidently integrate this surface mount transistor into power management, amplification, and signal control applications.
