onsemi 8-Bit Non-Inverting CMOS Bus Transceiver, Surface Mount SOIC 20-Pin MC74ACT245DWG
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 2.45mm |
| Length | 12.95mm |
| Model | MC74ACT245DWG |
| Mount Type | Surface |
| Output type | 3 State |
| Series | MC74ACT |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Polarity | Non-Inverting |
| Number Of Channels | 8 |
| Pin Count | 20 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | ACT |
| Logic Function | Transceiver |
| Minimum Supply Voltage | 4.5V |
| Maximum High Level Output Current | -24mA |
| Maximum Propagation Delay Time @ CL | 8ns |
| Maximum Low Level Output Current | 24mA |
| Output Level | CMOS |
| Input Level | TTL |
Key Features
- Features 8 channels for data transmission and reception.
- Operates with a minimum supply voltage of 4.5V and maximum of 5.5V.
- Non-inverting polarity with TTL input levels and CMOS output levels.
- Maximum propagation delay time at capacitive load is 8 ns for efficient performance.
- Designed for operation within a temperature range of -40°C to 85°C.
- Provides 3-state output type suitable for bus-oriented applications.
- Maximum output current of ±24mA to support various load requirements.
Product Description
The onsemi MC74ACT245DWG is an 8-bit non-inverting CMOS bus transceiver housed in a surface mount 20-pin SOIC package, designed for seamless integration into electronic systems requiring reliable data transmission.
Operating from a low voltage supply range between 4.5V and 5.5V, it offers TTL-compatible input levels and CMOS output levels, making it compatible with a variety of logic families. Its 3-state output configuration facilitates easy bus sharing and minimizes conflicts in multi-device systems.
With a maximum propagation delay of 8 ns at a capacitive load, this transceiver ensures prompt switching suitable for high-speed data communication scenarios. It supports 8 communication channels to handle parallel data paths effectively.
The device is robust across a wide operating temperature range from -40°C to 85°C, suitable for industrial and commercial electronics applications. Its mechanical dimensions (12.95 mm length and 2.45 mm height) and surface mount package type allow for compact PCB layouts.
Provides 8 independent channels for bidirectional data transfer. Non-inverting polarity ensures signal integrity during transmission. Wide voltage supply range enhances flexibility in system design. 3-state outputs enable multiple device bus sharing without interference.
TTL input and CMOS output compatibility for broad application use. Fast 8 ns propagation delay for efficient data handling. Compact 20-pin SOIC package suitable for surface mount assembly. This bus transceiver is ideal for industrial, laboratory, construction, and manufacturing electronics systems requiring durable and efficient data communication interfaces.
Discover more semiconductor components and electronic ICs at EnvMart for your design and production needs.
Explore more products in our Logic ICs category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates with a minimum supply voltage of 4.5V and a maximum of 5.5V.
This model supports 8 independent channels for bidirectional data transfer.
The maximum propagation delay time at a capacitive load is 8 ns, ensuring efficient performance.
It features TTL input levels and CMOS output levels, making it compatible with various logic families.
It is designed to operate within a temperature range of -40°C to 85°C.
It provides a 3-state output type suitable for bus-oriented applications.
It comes in a surface mount SOIC package with dimensions of 12.95 mm in length and 2.45 mm in height.
The maximum output current is ±24mA, supporting various load requirements.
Yes, it is ideal for industrial, laboratory, construction, and manufacturing electronics systems requiring efficient data communication.
The logic function of this device is a transceiver, facilitating data transmission and reception.
This model has a pin count of 20.
The country of origin for the MC74ACT245DWG is India.
