onsemi 400 V 1 A Schottky Diode Surface Mount 2-Pin SOD-323 Package S1GHE
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 0.75mm |
| Length | 2.3mm |
| Model | S1GHE |
| Width | 1.4mm |
| Mount Type | Surface |
| Series | S1GHE |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 400V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 50μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 20A |
| Maximum Forward Voltage Vf | 1.1V |
| Peak Reverse Recovery Time trr | 782ns |
| S1GHE | 1 A, 400 V Surface Mount Rectifiers |
Key Features
- Compact SOD-323 surface mount package with dimensions 2.3 mm length, 1.4 mm width, and 0.75 mm height.
- Low forward voltage drop of 1.1 V ensures efficient rectification performance.
- Peak reverse repetitive voltage of 400 V suitable for high voltage applications.
- Maximum continuous forward current of 1 A and peak forward surge current of 20 A.
- Robust operation temperature range from -55°C to 175°C enabled by glass passivated chip junction and green mold compound.
- Fast peak reverse recovery time of 782 ns reduces switching losses in power circuits.
- Two-pin configuration and single diode setup ideal for automated PCB assembly.
- Meets automotive standard AEC-Q101 ensuring reliability in automotive and industrial applications.
Product Description
onsemi S1GHE Schottky Diode in a 2-pin SOD-323 surface mount package rated for 400 V maximum reverse voltage and 1 A continuous forward current, designed for efficient, low-loss rectification.
This diode offers a low forward voltage drop of 1.1 V, minimizing power dissipation and heat generation during operation, which is critical in power management and switching applications.
The robust device withstands operating temperatures from -55°C up to 175°C, aided by a glass passivated chip junction and environmentally friendly green mold compound, ensuring longevity and reliability in harsh conditions.
Its peak reverse recovery time of 782 ns supports efficient switching with reduced electromagnetic interference. The diode has a peak non-repetitive forward surge current capability of 20 A accommodating transient overloads.
Compact dimensions (2.3 mm length, 1.4 mm width, 0.75 mm height) and surface mount package type allow for automated assembly on densely populated PCBs used in industrial, automotive, consumer electronics, and power supply systems.
Compact SOD-323 surface mount package with 2-pin footprint for automated PCB assembly. Low forward voltage drop ensures energy efficiency and less heat build-up. High voltage rating suitable for power conversion and protection circuits.
Wide operating temperature range enables use in automotive and industrial environments. Meets AEC-Q101 automotive standard for enhanced quality assurance. Fast recovery time aids in switching power supplies and rectifiers.
Single diode configuration simplifies circuit design applications. Ideal for use in industrial power systems, automotive electronics, consumer devices, and electronic instrumentation.
This Schottky diode from onsemi represents a reliable choice for power rectification in various electronics applications. Explore the Semiconductor category on EnvMart for compatible components and related products.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum reverse voltage rating of this Schottky diode is 400 V, making it suitable for high voltage applications.
This model has a maximum continuous forward current capacity of 1 A.
The SOD-323 package dimensions are 2.3 mm in length, 1.4 mm in width, and 0.75 mm in height.
The forward voltage drop of this diode is 1.1 V, which helps in minimizing power dissipation during operation.
The peak non-repetitive forward surge current capability of this model is 20 A, accommodating transient overloads.
The diode operates within a temperature range of -55°C to 175°C, suitable for various environments.
The peak reverse recovery time is 782 ns, which aids in reducing switching losses in power circuits.
This diode meets the AEC-Q101 automotive standard, ensuring reliability in automotive applications.
The S1GHE diode has a 2-pin configuration, designed for easy automated PCB assembly.
This diode is classified as a Schottky rectifier, known for its low forward voltage drop and fast switching capabilities.
The peak reverse current rating for this model is 50 μA, indicating its efficiency in operation.
The S1GHE diode is manufactured in India.
