Vishay 400 V 1 A General Purpose Fast Recovery Diode 2-Pin Surface Mount DO-214BA RGF1G-E3/67A
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 13in |
| Brand | Vishay |
| Height | 2.74mm |
| Length | 4.75mm |
| Model | RGF1G-E3/67A |
| Width | 2.9mm |
| Mount Type | Surface |
| Series | RGF1 |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-214BA |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | J-STD-020, UL 94 V-0, RoHS, J-STD-002, JESD 22-B102, JESD 201, AEC-Q101 |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 400V |
| Diode Configuration | Single |
| Rectifier Type | General Purpose |
| Peak Reverse Current Ir | 100μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 30A |
| Maximum Forward Voltage Vf | 1.3V |
| Peak Reverse Recovery Time trr | 150ns |
Key Features
- Surface mount type for compact PCB design applications.
- Maximum continuous forward current of 1 ampere ensuring reliable performance.
- Peak reverse repetitive voltage rating of 400 volts.
- Fast recovery time of 150 nanoseconds suitable for power rectification.
- Wide operating temperature range from -65°C to 175°C for robust industrial use.
- Low maximum forward voltage drop of 1.3 volts enhances efficiency.
- Compliant with automotive standard AEC-Q101 for stringent quality requirements.
- Compact dimensions with length 4.75 mm, width 2.9 mm, and height 2.74 mm.
Product Description
Vishay RGF1G-E3/67A is a general purpose fast recovery diode designed to handle a maximum continuous forward current of 1 ampere and a peak reverse repetitive voltage of 400 volts. It is housed in a low profile 2-pin DO-214BA surface mount package measuring 4.75 mm in length, 2.9 mm in width, and 2.74 mm in height. This diode offers a fast recovery time of 150 nanoseconds, making it ideal for power rectification applications requiring quick switching.
This diode operates reliably over a wide temperature range from -65°C to 175°C, supporting demanding industrial and automotive environments. Its low maximum forward voltage of 1.3 volts helps reduce power loss, enhancing overall efficiency. The product complies with automotive standard AEC-Q101 and meets various certifications such as RoHS, J-STD-020, UL 94 V-0, and JESD standards, which assure quality and environmental safety.
The Vishay RGF1G-E3/67A diode is widely used in power supply units, industrial machinery, automotive electronics, and general electronic component assemblies requiring high-efficiency rectification and durability. The compact surface mount package allows for efficient circuit board layout in space-constrained designs.
Surface mount type for compact PCB design applications. Maximum continuous forward current of 1 ampere ensuring reliable performance. Peak reverse repetitive voltage rating of 400 volts. Fast recovery time of 150 nanoseconds suitable for power rectification.
Wide operating temperature range from -65°C to 175°C for robust industrial use. Low maximum forward voltage drop of 1.3 volts enhances efficiency. Compliant with automotive standard AEC-Q101 for stringent quality requirements.
Compact dimensions with length 4.75 mm, width 2.9 mm, and height 2.74 mm. Certified standards including RoHS, J-STD-020, UL 94 V-0, J-STD-002, JESD 22-B102, JESD 201.
This diode suits industrial, automotive, manufacturing, and power electronic applications where fast switching and reliability are paramount. Browse related semiconductor and diode products in EnvMart for comprehensive electronic component sourcing.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this diode is 1 ampere.
The dimensions of the DO-214BA package are 4.75 mm in length, 2.9 mm in width, and 2.74 mm in height.
The recovery time for this fast recovery diode is 150 nanoseconds.
The operating temperature range is from -65°C to 175°C.
This diode complies with the automotive standard AEC-Q101.
The maximum forward voltage drop is 1.3 volts.
The diode meets several certifications including RoHS, J-STD-020, UL 94 V-0, J-STD-002, JESD 22-B102, JESD 201, and AEC-Q101.
This diode uses a surface mount type for installation.
It is suitable for applications in power supply units, industrial machinery, automotive electronics, and general electronic component assemblies requiring high-efficiency rectification.
This diode has 2 pins.
The peak non-repetitive forward surge current rating is 30 amperes.
